AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 132

Category address: [Function] - [Function setting] - [Option] - [slotn] - [OP-03] or
[Function] - [Function setting] - [Option] - [slotn] - [OP-04]
OP-03: Option RS-422 / 485 Serial Interface
OP-04: Option RS-232C Serial Interface
Category
address
symbol
03 f- 1
Output data
04 f- 1
03 f- 2
Communication
04 f- 2
mode
03 f- 3
Baud rate
04 f- 3
03 f- 4
Parity check
04 f- 4
03 f- 5
Charactor length
04 f- 5
03 f- 6
Stop bits
04 f- 6
03 f- 7
Terminator
Name
When jet stream mode of
coummnication mode [r5 f- 2] is used,
1, 2 or 3 can be selected. And if freeze
mode is used in jet stream mode, output
is stoped.
1: Displayed value
2: Gross value
3: Net value
4: Tare value
5: Gross value/ Net value/ Tare value
6: Displayed value with material code
7: Gross value with material code
8: Net value with material code
9: Tare value with material code
10: Gross value/ Net value/ Tare value
with material code
1: Stream mode
2: Auto print mode
3: Manual print mode
4: Print at total
5: Jet stream mode
6: Command mode
1: 600 bps
2: 1200 bps
3: 2400 bps
4: 4800 bps
5: 9600 bps
6: 19200 bps
7: 38400 bps (Command mode can not
be selected)
0: Not used
1: Odd
2: Even
7: 7 bits
8: 8 bits
1: 1 bit
2: 2:bits
1: CR
Descriptions
CR: 0Dh
Page 130
slot n : slot number
Range
and Default
choices
1 to 10 1
1 to 6 6
1 to 7 5
0 to 2 0
7, 8 8
1 to 2 1
1 to 2 2
AD-4402
