8.9. Analog Output of Option OP 8.9. Analog Output of Option OP- - - - 07
8.9. 8.9. Analog Output of Option OP Analog Output of Option OP
This option outputs DC current that is proportion to the display value.
Factory adjusted to 4 mA output at zero display and 20 mA output at full scale.
Analog output
Output voltage
Adaptable resistance
Update ratio
Zero temperature coefficient
Span temperature coefficient
Non-linearlity
Resolution
Connection
Span adjustment screw
adjusted in factory.
Zero adjustment screw
adjusted in factory.
Settings of Parameters
Refer to "10.4. Parameter List" of the function list.
Output current
22mA
When setting to
[ 07 f- 2 ] [ 100 . 0 0 ]
[ 07 f- 3 ] [ 0 . 0 0 ]
When setting to
[ 07 f- 2 ] [ 0 . 0 0 ]
[ 07 f- 3 ] [ 50 . 0 0 ]
2mA
AD-4402
Contact to ground
11 V DC min.
0
100 times per second with Sampling frequncy divider
[genf- 3]
150 ppm/
150 ppm/
0.1% max.
Smaller value of either 1/40000 or resolution of display
20mA
4mA
0.00kg
~ 500
max.
max.
AD-4402
OP-07 inside
Constant current source
10V max.
Connect shield
50.00kg
Page 95
07
07 07
The output voltage varies
according to resistor value.
Output current
1
+
2
-
3
FG
FG
When setting to
[ 07 f- 2 ] [ 0 . 0 0 ]
[ 07 f- 3 ] [ 100 . 0 0 ]
100.00kg
Resistor
Weighing
