Editing Full Parameters of a Material Code

Editing Full Parameters of a Material Code
6.1.5. 6.1.5. Editing Full Parameters of a Material Code Editing Full Parameters of a Material Code
A material code consists of the following parameters.
Name
Material Code
Material name
Material Hopper No.
Final
Free Fall
Preliminary
Optional Preliminary
Over
Under
Zero Band
Full
Tare
Supplementary Flow Open Timer
Supplementary Flow Close Timer
Automatic Free Fall Range
Initial Dribble Flow
Initial Medium Flow
Total Weight
Total Count
These parameters are stored in backup memory even without power.
Refer to the backup method [0tHf-11] of the function list.
Caution
If the flash memory is selected for memory backup [0tHf
built-in automatic program mode is stopped.
Edit a Material Code
Step 1 Press and hold the ENTER key and press the
Then menu
Step 2 Press the ENTER key to enter the material code edit. Then menu
Step 3 Press the ENTER key to enter menu edit.
Step 4 Select the material code using the numerical keys and press the ENTER.
Step 5 Enter the material name using the alpanumerical keys and press the ENTER key.
Step 5 Edit other parameters using the numerical keys, ENTER key and
Step 6 If you want to finish the change, press the ESC key several times to return to the
weighing mode.
AD-4402
Display Name
Code
Mat Name
Mat Hopper
Final
Free Fall
Preliminary
OP.Preliminary
Over
Undr
Zero Band
Full
Tare
SF open timer
SF close
AFFC range
Initial DF
Initial MF
Tot
Tot#
MatEdit
blinks.
Display
Symbol
Code
Hopper
Final
FFall
Plm
OPPlm
Over
Undr
0Band
Full
Tare
SFOT
SFCT
AFFC
IDF
IMF
Tot
Tot#
key.
Page 27
Display
Memory
Example
11
grain
1
10.00 kg
0.01 kg
1.00 kg
Backed up
2.00 kg
RAM
0.10 kg
( factory
0.10 kg
setting)
0.02 kg
or
0.05 kg
flash
5.00 kg
memory
0.00 s
0.0 s
0.00 kg
0.00 kg
0.00 kg
10.00 kg
Backed up
1
RAM
0tHf- - - - 11 11], the current
0tHf 0tHf 11 11
Edit
key.
blinks.
