AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 112

Category address: [Function] - [Function setting] - [General] - [Sub-display]
Category
address
symbol
5Ubf- 1
Weighing display
When custom format is used (When [5Ubf- 1] [1] ), set items to be displayed in the
sub-display.
Item index number to be displayed. 32 items of name and number can be set in maximum.
Odd: Input the name of the selected item using alphanumeric characters.
Even: Input the number concerning the item.
5ub f 1
Sub F1-3
hopper
Name of
the item
Number Name and Number to Display the Item
0 Not displayed
1 Material
2 Hopper
3 Final
4 Free fall
5 Preliminary
6 Optional preliminary
7 Over
8 Under
9 Zero Band
10 Full (full filling)
11 Tare
12 Supplementary flow open timer
13 Supplementary flow close timer
14 Automatic Free Fall Compensation
15 Internal reserved
16 Internal reserved
17 IDF at initial flow sequence
18 MDF at initial flow sequence
19 Total weight
20 Total count
Recipe , rCode
21
22 Total weight for recipe mode
23 Total count for recipe mode
Name
0: Basic format
1: Custom format
[name]
19
Descriptions
/Row/Col/Dig
0 16 5
Row size
Page 110
Range
and
choices
0 to 1
Information of
key operation
Resize the item selected.
Columsize
0 to 3 0 to26
Default
0
Figures
1 to12
AD-4402
