Rs-232C Interface Of Option Op-04 - AND Multi Function Weighing Indicator AD-4402 Instruction Manual

8.7. RS 8.7. RS- - - - 232C Interface of Option OP
8.7. 8.7. RS RS
The RS-232C are used to connect to the DEC (modem).
The command and parameters of RS-232C is the same as the built-in RS-485.
Transmission system
Data length
Start bit
Parity bit
Stop bits
Baud rate
Caution
Either option OP-03 or OP-04 can be installed.
Connection
25
14
Settings of Parameters
Refer to "10.4. Parameter List" of the function list.
AD-4402
232C Interface of Option OP- - - - 04
232C Interface of Option OP 232C Interface of Option OP
EIA RS-232C,
Asynchronous, bi-directional, half-duplex
7 bits ot 8 bits
1 bit
Odd, Even, not used
1 bit, 2 bits
600 bps, 1200 bps, 2400 bps, 4800 bps, 9600 bps, 19200
bps
AD-4402
OP-04 inside
13
1
Page 93
1 FG
FG
2 TXD
3 RXD
4 RTS
5 CTS
6 DSR
7 SG
SG
20 DTR
04
04 04
