11.1. Dimensions

11.1.
11.1. 11.1.

11.2. Accessories

11.2.
11.2. 11.2.
Capacity label ...................................................... 1
I/O connector ....................................................... 1
I/O connector cover ............................................. 1
RS-485, terminator resistor 100
Cover of power supply terminal ........................... 1
Cover of RS-485 and current loop ....................... 1
Cover of loadcell teminal...................................... 1
Rubber packing for mounting to panel ................. 1
AD-4402
Dimensions
Dimensions Dimensions
Accessories
Accessories Accessories
...................... 1
Panel cutout size
