AND Multi Function Weighing Indicator AD-4402 Instruction Manual page 126

Category address: [Function] - [Function setting] - [Control I/O Function] - [Output]
The list to assign the function for the output terminal of the I/O
No. Function description
0 No function
1 Stable
2 Zero band
3 Full (Full filling)
4 Full flow
5 Medium flow
6 Dribble flow
7 Over
8 OK
9 Under
10 Internal reservation
11 Internal reservation
12 Mixing
13 Discharge (Open the dscharge gate) 43 Material hopper 9
14 Batch finish
15 Recipe finish
16 Discharge finish
17 Mixing finish
18 Nozzle down
Online. If sequence is
19 enabled, 0.5 sec. pulse is
output.
Weighing sequence in
20
process
Input acknowledge.
21 If there is a input signal, 0.5
sec. pulse is output.
22 Weighing sequence error
23 Alram 1
24 Alram 2
25 Zero error
Capacity exceeded
26
(Out of range)
27 Buzzer
28 During tare
29 Center of zero
Full flow:
Medium flow:
Dribble flow:
No.
30 Gross display
31 Net display
32 During hold
33 Internal reservation
34 Internal reservation
35 Material hopper 1
36 Material hopper 2
37 Material hopper 3
38 Material hopper 4
39 Material hopper 5
40 Material hopper 6
41 Material hopper 7
42 Material hopper 8
44 Material hopper 10
45 Material hopper 11
46 Material hopper 12
47 Material hopper 13
48 Material hopper 14
49 Material hopper 15
50 Material hopper 16
51 Material hopper 17
52 Material hopper 18
53 Material hopper 19
54 Material hopper 20
55 Material hopper 1 FF
56 Material hopper 1 MF
57 Material hopper 1 DF
58 Material hopper 2 FF
59 Material hopper 2 MF
FF
MF
DF
Function description
Page 124
No.
Function description
60 Material hopper 2 DF
61 Material hopper 3 FF
62 Material hopper 3 MF
63 Material hopper 3 DF
64 Material hopper 4 FF
65 Material hopper 4 MF
66 Material hopper 4 DF
67 Material hopper 5 FF
68 Material hopper 5 MF
69 Material hopper 5 DF
70 Material hopper 6 FF
71 Material hopper 6 MF
72 Material hopper 6 DF
73 Material hopper 7 FF
74 Material hopper 7 MF
75 Material hopper 7 DF
76 Material hopper 8 FF
77 Material hopper 8 MF
78 Material hopper 8 DF
79 Material hopper 9 FF
80 Material hopper 9 MF
81 Material hopper 9 DF
82 Material hopper10 FF
83 Material hopper10 MF
84 Material hopper10 DF
AD-4402
