Category address: [Function] - [Function setting] - [Option] - [slotn] - [OP-07]
OP-07: Option Analog Output
Category
address
symbol
07 f- 1
Out put data
07 f- 2
Weight at 4 mA
07 f- 3
Weight at 20 mA
AD-4402
Name
1: Displayed value
2: Gross value
3: Net value
Set the weight value when 4 mA is
output.
Set the weight value when 20 mA is
output.
Descriptions
Page 133
slot n : slot number
Range
and
Default
choices
1 to 3
1
-999999
to
0
9999999
-999999
to
16000
9999999
