78 C 5: P
HAPTER LANNING THE
Creating or
Modifying a Site
3C M S
OM OBILITY YSTEM
Table 12 Toolbar icons available in RF Planning Tools (continued)
Option Description
Show 802.11a RF coverage in the floor display area.
Show 802.11b RF coverage in the floor display area.
Show 802.11g RF coverage in the floor display area.
Hide display of 802.11 RF coverage in the floor display area.
A site is a folder that contains the buildings in the network plan. A site
usually represents a campus of geographically colocated buildings. If your
network plan encompasses multiple campuses, create a site for each
campus.
To create or modify a site
1 Select the RF Planning tool bar option.
2 In the Organizer panel, click the name of the network plan.
3 Perform one of the following steps:
If you are creating a new site, click on the network plan name in
the Organizer panel and select Create Site in the Task List panel.
A series of dialog boxes prompts you for information about the
new site.
If you are modifying an existing site, click on the plus sign next to
the network plan to expand it, then click on the name of the site
you want to modify. Information about the site appears in the
Content panel.
The following figure illustrates the information displayed in the Content
panel for a site. Note that this information is the same as the information
for which you are prompted when you create a site.
