462 C 17: M
HAPTER
Using the Traffic
Summary View
N
ONITORING THE ETWORK
2 Choose Manage > RF Link Test in the Task panel to run a link test and
display the Link Test results dialog, as shown below.
3 Click the Refresh button to perform another link test and repopulate the
RF Link Test table with new data.
The Traffic Summary view displays network usage and RF summary data.
3WXM shows both traffic and RF statistics for Radio, AP, Floor, Building,
and Site options, but only traffic data is applicable for MS, Mobility
Domain, and Network Plan options. Click the tabular icon
graph icon
The following options are available for WX, Mobility Domain, and
Network Plan:
1 Hour
24 Hour
7 Days
30 Days
to switch between the chart and table views.
or the
