xStack
Type
Information about firmware on the Switch can be viewed in the Firmware Management table in the same window. It holds the
following information:
Parameter Description
ID The user-defined Section ID of the firmware on the Switch.
Boot Status The firmware that is currently being run on the Switch will be identified in this field with the term
"Boot".
The runtime version of the firmware.
Version
Size The size of the firmware, in bytes.
Date The date that the firmware was added to the Switch.
From The IP address of the Server from which the firmware came.
User The name of the user who downloaded the firmware.
Set Boot Click the Apply button in this field to set the firmware version to be used upon the next boot up of
the Switch.
Delete Click the X in this column to permanently delete the corresponding firmware from the Switch.

Download Configuration File

To download a settings file from a TFTP server, click Maintenance > TFTP Service > Download Configuration File:
Enter the IP address of the TFTP server and specify the location of the switch settings file on the TFTP server.
Click Start to record the IP address of the TFTP server and to initiate the file transfer.

Upload Configuration

To upload the switch settings to a TFTP server, click Maintenance > TFTP Services > Upload Configuration:
Enter the IP address of the TFTP server and the path and filename for the switch settings on the TFTP server.
Click Start to record the IP address of the TFTP server and to initiate the file transfer.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Specify the purpose of the firmware:
Download: Clicking this radio button will specify a download to the Switch. This will be the
firmware that the Switch will immediately use.
Update: Clicking this radio button will save the firmware to the Switch's memory but not
configure the Switch for this firmware. The Switch may hold two firmware versions specified
as Section 1 and Section 2.
Figure 9- 2. Download Settings from TFTP Server window
Figure 9- 3. Upload Settings to TFTP Server window
