Tool Tips

In the Topology view window, the mouse plays an important role in configuration and in viewing device information. Setting the
mouse cursor over a specific device in the topology window (tool tip) will display the same information about a specific device as
the Tree view does. See the window below for an example.
Setting the mouse cursor over a line between two devices will display the connection speed between the two devices, as shown
below.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Layer 2-member switch.
Layer 3 member switch
Member switch of other group
Layer 2 candidate switch
Layer 3 candidate switch
Unknown device
Non-SIM devices
Figure 10- 6. Device Information Utilizing the Tool Tip
