D-Link DES-3526 - Switch - Stackable User Manual page 136

xStack
The following window is the CPU Interface Filtering Rule Configuration for Packet Content.
Figure 6- 97. CPU Interface Filtering Rule Configuration window for Packet Content Mask
To set the rule for CPU Packet Content, adjust the following parameters and click Apply.
Parameters Description
Profile ID This is the identifier number for this profile set.
Mode Select Permit to specify that the packets that match the access profile are forwarded by the
Switch, according to any additional rule added (see below).
Select Deny to specify that packets that match the access profile are not forwarded by the
Switch and will be filtered.
Access ID Type in a unique identifier number for this access. This value can be set from 1 - 65535.
Type Selected profile based on Ethernet (MAC Address), IP address or Packet Content.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
121
