xStack
From Port/To
Use the drop-down menu to select a range of ports to be configured.
Port VLAN ID
Use the drop-down menu to Enable or Disable the advertise Port VLAN ID.
VLAN Name
Use the drop-down menu to Enable or Disable the advertised VLAN ID, VLAN Name or All.
Protocol Identify
Use the drop-down menu to Select the advertised Protocol Identity. Select EAPOL, LACP,
GVRP, STP or All.
Click Apply to implement changes made.

802.3 Extension LLDP Port Settings

To view this window, click Configuration > LLDP > 802.3 Extension LLDP Port Settings
The following parameters can be set:
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Figure 6- 129. 802.3 Extension LLDP Port Settings window
