xStack
Parameter
Instance ID
Internal cost
(0=Auto)
Priority
Click Apply to implement changes made.

STP Instance Settings

The following window displays MSTIs currently set on the Switch. To view the following table, click Configuration > Spanning
Tree > STP Instance Settings:
The following information is displayed:
Parameter
Instance Type
Instance Status
Instance Priority
Click Apply to implement changes made.
To acquire more detailed information on a particular STP Instance, click its hyperlinked Instance Type, which will display the
following read-only window.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Description
Displays the MSTI ID of the instance being configured. An entry of 0 in this field denotes the
CIST (default MSTI).
This parameter is set to represent the relative cost of forwarding packets to specified ports
when an interface is selected within a STP instance. The default setting is 0 (auto). There are
two options:
0 (auto) - Selecting this parameter for the internalCost will set quickest route
•
automatically and optimally for an interface. The default value is derived from the
media speed of the interface.
value 1-2000000 - Selecting this parameter with a value in the range of 1-2000000
•
will set the quickest route when a loop occurs. A lower Internal cost represents a
quicker transmission.
Enter a value between 0 and 240 to set the priority for the port interface. A higher priority will
designate the interface to forward packets first. A lower number denotes a higher priority.
Figure 6- 32. STP Instance Table window
Description
Displays the instance type(s) currently configured on the Switch. Each instance type is
classified by a MSTI ID. CIST refers to the default MSTI configuration set on the Switch.
Displays the current status of the corresponding MSTI ID
Displays the priority of the corresponding MSTI ID. The lowest priority will be the root bridge.
57
