MAC Address

This allows the Switch's dynamic MAC
address forwarding table to be viewed. When
the Switch learns an association between a
MAC address and a port number, it makes an
entry into its forwarding table. These entries
are then used to forward packets through the
Switch.
To view the MAC Address forwarding table,
click, Monitoring > MAC Address:
The following fields can be viewed or set:
Parameter
VLAN ID
MAC Address
Find
VID
MAC Address
Port
Learned
Next
View All Entry
Delete All Entry
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Description
Enter a VLAN ID for the forwarding table to be browsed by.
Enter a MAC address for the forwarding table to be browsed by.
Allows the user to move to a sector of the database corresponding to a user defined port,
VLAN, or MAC address.
The VLAN ID of the VLAN the port is a member of.
The MAC address entered into the address table.
The port that the MAC address above corresponds to.
How the Switch discovered the MAC address. The possible entries are Dynamic, Self, and
Static.
Click this button to view the next page of the address table.
Clicking this button will allow the user to view all entries of the address table.
Clicking this button will allow the user to delete all entries of the address table.
Figure 8- 16. MAC Address Table window
