xStack
The following fields can be set or viewed:
Parameter
Time Interval
Record Number
64
65-127
128-255
256-511
512-1023
1024-1518
Show/Hide
Clear
View Table
View Line Chart
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Description
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Select number of times the Switch will be polled between 20 and 200. The default value is 20.
The total number of packets (including bad packets) received that were 64 octets in length
(excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 65 and 127
octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 128 and 255
octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 256 and 511
octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 512 and 1023
octets in length inclusive (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) received that were between 1024 and
1518 octets in length inclusive (excluding framing bits but including FCS octets).
Check whether or not to display 64, 65-127, 128-255, 256-511, 512-1023, and 1024-1518
packets received.
Clicking this button clears all statistics counters on this window.
Clicking this button instructs the Switch to display a table rather than a line graph.
Clicking this button instructs the Switch to display a line graph rather than a table.
