xStack
NOTE: When configuring the ACL mode function of the IP-MAC binding function, please pay close
attention to previously set ACL entries. Since the ACL mode entries will fill the first two available
access profiles and access profile IDs denote the ACL priority, the ACL mode entries may take
precedence over other configured ACL entries. This may render some user-defined ACL
parameters inoperable due to the overlapping of settings combined with the ACL entry priority
(defined by profile ID). For more information on ACL settings, please see "Configuring the Access
Profile" section mentioned previously in this chapter.
NOTE: Once ACL profiles have been created by the Switch through the IP-MAC binding function,
the user cannot modify, delete or add ACL rules to these ACL mode access profile entries. Any
attempt to modify, delete or add ACL rules will result in a configuration error as seen in the previous
figure.
NOTE: When uploading configuration files to the Switch, be aware of the ACL configurations
loaded, as compared to the ACL mode access profile entries set by this function, which may cause
both access profile types to experience problems.
The user may view the configurations on a port-by-port basis by clicking the View button under the Display heading of the
corresponding port entry. These entries cannot be modified or deleted, and new rules cannot be added. Yet, these windows will
offer vital information to the user when configuring other access profile entries. Note that the option, Flow Meter, is only
available to be configured for ACL owner. Click Next to view the next page of rules. The user may also search for an entry by
Access ID by entering that ID into the field and clicking Find.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Figure 6- 104 Access Rule Table for IP-MAC Binding rule (Modify)
125
