xStack
Access ID
Type
Priority (0-7)
Replace Dscp with
(0-63)
VLAN Name
Source MAC
Destination MAC
802.1p (0-7)
Ethernet Type
Port Number
Time Range
To view the settings of a previously correctly configured rule, click
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Select Deny to specify that packets that match the access profile are not forwarded by the
Switch and will be filtered.
Type in a unique identifier number for this access. This value can be set from 1 - 65535.
Auto Assign – Checking this field will instruct the Switch to automatically assign an Access
ID for the rule being created.
Selected profile based on Ethernet (MAC Address), IP address or Packet Content Mask.
Ethernet instructs the Switch to examine the layer 2 part of each packet header.
•
IP instructs the Switch to examine the IP address in each frame's header.
•
Packet Content Mask instructs the Switch to examine the packet header
•
This parameter is specified if you want to re-write the 802.1p default priority previously set in
the Switch, which is used to determine the CoS queue to which packets are forwarded to.
Once this field is specified, packets accepted by the Switch that match this priority are
forwarded to the CoS queue specified previously by the user.
Replace Priority with − Click the corresponding box if you want to re-write the 802.1p default
priority of a packet to the value entered in the Priority (0-7) field, which meets the criteria
specified previously in this command, before forwarding it on to the specified CoS queue.
Otherwise, a packet will have its incoming 802.1p user priority re-written to its original value
before being forwarded by the Switch.
For more information on priority queues, CoS queues and mapping for 802.1p, see the QoS
section of this manual.
Select this option to instruct the Switch to replace the DSCP value (in a packet that meets
the selected criteria) with the value entered in the adjacent field.
Allows the entry of a name for a previously configured VLAN.
Source MAC Address - Enter a MAC Address for the source MAC address.
Destination MAC Address - Enter a MAC Address mask for the destination MAC address.
Enter a value from 0 to 7 to specify that the access profile will apply only to packets with this
802.1p priority value.
Specifies that the access profile will apply only to packets with this hexadecimal 802.1Q
Ethernet type value (hex 0x0-0xffff) in the packet header. The Ethernet type value may be
set in the form: hex 0x0-0xffff, which means the user may choose any combination of letters
and numbers ranging from a-f and from 0-9999.
Enter the switch port number(s) to which you wish this rule to apply.
Enter a Time Range that will set specific times when this access rule will be implemented on
the Switch.
in the Access Rule Table to view the following window:
