xStack
The following parameters can be set, for IP:
Parameter
Profile ID (1-255)
Type
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Figure 6- 64. Access Profile Configuration window (IP)
Description
Type in a unique identifier number for this profile set. The number is used to set the relative
priority for the profile. Priority is set relative to other profiles where the lowest profile ID has the
highest priority. If a conflict occurs among configured access rules, the profile ID establishes
relative priority of the rules. The value can be set from 1 to 255 however there is a limit to the
total number of profiles that can be created.
Select profile based on Ethernet (MAC Address), IP address or packet content mask. This will
change the menu according to the requirements for the type of profile.
Select Ethernet to instruct the Switch to examine the layer 2 part of each packet
•
header.
Select IP to instruct the Switch to examine the IP address in each frame's header.
•
Select Packet Content Mask to specify a mask to hide the content of the packet
•
header.
96
