Port Utilization
The Utilization window displays the percentage
of the total available bandwidth being used on
the ports.
To view the port utilization, click Monitoring >
Port Utilization:
The following field can be set:
Parameter Description
Time Interval
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
Section 8
Figure 8- 1. Utilization window
204
