Advanced Settings

The Switch Information (Advanced Settings) window contains the main settings for all major functions for the Switch. To view
this window click, Configuration > Advanced Settings.
Parameter
Serial Port Auto
Logout Time
MAC Address Aging
Time
IGMP Snooping
GVRP Status
Telnet Status
TCP Port Number (1-
65535)
Web Status
Web TCP Port
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Figure 6- 3. Switch Information (Advanced Settings) window
Description
Select the logout time used for the console interface. This automatically logs the user out
after an idle period of time, as defined. Choose from the following options: 2 Minutes, 5
Minutes, 10 Minutes, 15 Minutes or Never. The default setting is 10 minutes.
This field specifies the length of time a learned MAC Address will remain in the forwarding
table without being accessed (that is, how long a learned MAC Address is allowed to remain
idle). To change this, enter a different value representing the MAC address age-out time in
seconds. The MAC Address Aging Time can be set to any value between 10 and 1,000,000
seconds. The default setting is 300 seconds.
To enable system-wide IGMP Snooping capability select Enabled. IGMP snooping is
Disabled by default. Enabling IGMP snooping allows you to specify use of a multicast router
only (see below). To configure IGMP Snooping for individual VLANs, use the IGMP
Snooping window under the IGMP folder.
Use this pull-down menu to enable or disable GVRP on the Switch.
Telnet configuration is Enabled by default. If you do not want to allow configuration of the
system through Telnet choose Disabled.
The TCP port number. TCP ports are numbered between 1 and 65535. The "well-known"
TCP port for the Telnet protocol is 23.
Web-based management is Enabled by default. If you choose to disable this by selecting
Disabled, you will lose the ability to configure the system through the web interface as soon
as these settings are applied.
The TCP port number currently being utilized by the Switch to connect to the web interface.
30
