xStack
Type
VLAN
Source Mac
Destination Mac
802.1p
Ethernet type
The window shown below is the Access Profile Configuration window for IP.
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
a limit to the total number of profiles that can be created.
Select profile based on Ethernet (MAC Address), IP address or packet content mask. This
will change the menu according to the requirements for the type of profile.
Select Ethernet to instruct the Switch to examine the layer 2 part of each packet
•
header.
Select IP to instruct the Switch to examine the IP address in each frame's header.
•
Select Packet Content Mask to specify a mask to hide the content of the packet
•
header.
Selecting this option instructs the Switch to examine the VLAN identifier of each packet
header and use this as the full or partial criterion for forwarding.
Source MAC Mask - Enter a MAC address mask for the source MAC address.
Destination MAC Mask - Enter a MAC address mask for the destination MAC address.
Selecting this option instructs the Switch to examine the 802.1p priority value of each packet
header and use this as the, or part of the criterion for forwarding.
Selecting this option instructs the Switch to examine the Ethernet type value in each frame's
header.
95
