xStack
Figure 6- 65. Access Profile Configuration window (Packet Content Mask)
This screen will aid the user in Switch to mask packet headers beginning with the offset value specified. The following fields are
used to configure the Packet Content Mask:
Parameter Description
Profile ID (1-255) Type in a unique identifier number for this profile set. This value can be set from 1 to 255.
Type Select profile based on Ethernet (MAC Address), IP address or Packet Content Mask. This will
change the menu according to the requirements for the type of profile.
Offset This field will instruct the Switch to mask the packet header beginning with the offset value
specified:
®
DES-3500 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
Select Ethernet to instruct the Switch to examine the layer 2 part of each packet
•
header.
Select IP to instruct the Switch to examine the IP address in each frame's header.
•
Select Packet Content Mask to specify a mask to hide the content of the packet
•
header.
value (0-15) - Enter a value in hex form to mask the packet from the beginning of the
•
98
