50
Cable Connectors
J100 (Side 2)
J5
Cable Routing and Pinouts
From
J2
J5
J6
J100
J2: MCBL203A, System Status Pinout
Refer to "Power Distribution Board (MSMT498 or MSMT499)" for the pinout of the system
status cable. See table "J1: MCBL203A, LCD Board System Status" on page 53.
J5: MCBL229A, Disk Drive LCD Pinout
Refer to "Disk Drive Section (MESAN52)" for the pinout of the RAID LCD cable. See table
"J2: MCBL229A, RAID LCD Cable" on page 57.
J6: MCBL230A, Disk Drive LED Pinout
Refer to "RAID Disk Drive Section (MESAN52)" for the pinout of the RAID LED cable.
See table "J3: MCBL230A, RAID LED Cable" on page 57.
2
J6
Cable
MCBL203A, system status
MCBL229A, LCD
MCBL230A, LED
MCBL208A, power on/off
To
Power distribution board
(MSMT498), J1
Disk drive section, J2
Disk drive section, J3
Keyswitch
