Avoiding Electrostatic Discharge

Sensitive components inside the base unit can be damaged by static electricity. To protect
against this possibility, take the following precautions when working with the system's
internal components.
u
Touch the bare metal of the base unit to ensure the base unit and your body are at the
same electric potential.
u
Handle all printed circuit boards as little as possible and by the edges only. Leave new
parts in their protective packaging until you install them.
u
Use a disposable or reusable antistatic wrist strap when servicing or upgrading the
system. Once a disposable wrist strap is used, it cannot be used again.
u
A reusable antistatic wrist strap can be attached to any bare metal part of the base unit.
The metal conductor in the elastic sleeve of reusable antistatic straps must contact bare
skin.

Opening the Base Unit

CAUTION The system produces high-leakage current. Flip the circuit breaker (if included) to the OFF
position when servicing or upgrading the base unit.
Tools are not required to remove the side panels because twist locks secure the panels to the
unit. The following table shows which panel to remove to access the internal components.
Panel
Right side
Left side
Both
NOTE The redundant power supplies can be removed without taking off either of the side panels.
Side panel removal is necessary for removal and replacement of the fixed mount power
supplies.
CAUTION Use caution to avoid injury when removing side panels and other hardware.
Components
System board, memory, processors, main cooling fans
AC section for redundant power supply only
CD-ROM drive, floppy disk (or combo) drive, power distributions board
assembly; 5.25-inch option devices, LCD board, RAID section
