Maintenance and Troubleshooting
RS232 Portl: or
RS232 Port2: or
Modem Port:
Make a selection
Reset
Exit
RS232 Port1 Reset: or
RS232 Port2 Resets or
Modem Port Reset:
Do you want to continue?
Yes
Cancel
RS232 Portl Reset: or
RS232 Port2 Reset: or
Modem Port Reset:
Reset in Progress
Exit
RS232 Portl Reset: or
RS232 Port2 Reset: or
Modem Port Reset:
Reset Successfully
Completed
Exit
If you want to reset the
RS-232 ports or the
modem, select "Reset."
Select "Yes" to start the
reset.
This screen appears,
indicating that the reset is in
progress.
If the reset is completed
successfully, this screen
appears.
Maintenance 5-27
