Programming Procedures
Step
4. Assign or remove DID
trunk
To assign DID trunk to
block
To remove
from block
Note: An alternate method for steps 3 and 4 is to select Entry
Mode (F6), identify the DID trunk (dial or type trunk number,
logical ID, or slot and port no.), and select Enter (F10) to assign
to the block, or select Delete (F8) to remove from the block.
5. When all entries are
complete

DID Trunk Type

step
1. Display DID Trunks
screen and select DID
Trunk Type
Console
Press line
button for each
trunk to turn
green LED on
Press line
DID trunk
button for each
trunk to turn
green LED off
Exit
Exit
Exit
Console
LinesTrunks
D I D
Type
PC
Press function
keys for each
trunk to make
letter "G"
appear on
screen
Press function
key for each
trunk to erase
letter "G"
F 5
F 5
F 5
PC
F 4
F 4
F 4
DID Trunks 4-63
