Installation
Table 3-12 Artificial Transmit Line Options
Position
1
2
3
Connect the CSU to the 100D Module and the DS1
Network
Follow these steps to connect the ESF T1 CSU to the 100D
module and the DS1 network (see Figure 23):
1.
Connect the D8W cord from the 100D module (see Table
3-13) to the rear panel of the CSU in one of the following
ways:
directly to the wire-wrap connector (see Table 3-14)
with a special cable adapter to the 15-pin DTE female
connector (see Table 3-15)
2. Connect the network cord to the CSU in one of the following
ways:
directly to the wire-wrap connector (see Table 3-14)
with a special cable adapter to the NET 15-pin male
connector (see Table 3-16)
Option
0.0 dB
7.5 dB
15.0 dB
Channel Service Unit 3-31
Distance
0—1000 ft
1000—2000 ft
2000—3000 ft
