AT&T MERLIN LEGEND Installation & Maintenance Manual page 504

Maintenance and Troubleshooting
Line/Trunk
Make a selection
Status
Busy Out
Restore
Exit
Restore Line/Trunk
Restore in Progress
Exit
Restore Line/Trunk
Restore Successfully
Completed
Exit
Restore Line/Trunk
Restore FAILED
Exit
RS-232 or Modem Port Reset. Select the desired RS-232 port
or the modem from the Port menu.
Note: Port 1 is the system programming/maintenance port and
Port 2 is the SMDR port.
5-26 Maintenance
:
XXXX
:
XXXX
:
XXXX
:
XXXX
Select "Restore."
This screen appears,
indicating that the restorers
in progress.
If the restore is completed
successfully, this screen
appears.
If the restore fails,
screen appears.
this
