Installation
(1) Route the station wires underneath the termination
block and through the fanning slots.
(2) Insert the conductors into the designated 110
connecting blocks already on the termination block.
Follow the color sequence shown in Figure 43.
(3) Use the D-impact tool to seat the conductors (see
Figure 41).
(4) Remove any insulation fragments with a spudger.
d.
Repeat steps a through c above
block.
5. Mount the wire troughs.
6. As needed, mount the D-rings.
7. Label the D8W cords, termination blocks, and DIW cords
properly (see "Label the System Wiring" in this chapter).
8. Plug one end of a D8W cord into the station jack on the CU
module and the other end into the designated jack on the
termination block. Do this for all stations.
9. Dress the wires through the wire troughs and D-rings (see
Figure 44).
SYSTIMAX
SYSTIMAX is a wiring method that uses kits containing all the
hardware you need to build a cross-connect field between the
CU and the station jack.
CAUTION:
To avoid coupling power supply noise onto system wiring,
allow at least 3 inches of clearance between the basic
carrier's power supply and any wiring or termination
hardware located left of the CU.
3-90 System Wiring
for each termination
