Installation
5. Locate the KF label that is on the jack numbering labels sheet
packed with the feature module; stick it on the wire manager
at the base of the module.
Install the Feature Module in the Processor Module
Before you install the processor module in the carrier, you must
install the feature module in the processor module. The feature
module comes in two models: a model for the small processor
module and a model for the large processor module.
Follow these steps to install the feature module (see Figure 19):
1.
Unpack the feature module.
2. Stick the round feature module label to the front of the
processor module housing.
3. Lay the processor module on its left side.
4. Align the connectors on the feature module with the
connectors in the processor module.
5. Firmly press the feature module into the processor module.
Insert the Processor Module
CAUTION:
Remove the protective cover from the processor module's
gold-finger connector before installing the module into the
carrier.
Follow these steps to insert the processor module (see
Figure 20):
1. Lower the processor module onto the rod on the carrier in
slot 00.
2. Be sure that the connector on the module mates properly with
the connector on the carrier.
3. Swing the processor module into the slot.
3-10 The Control Unit
