Installation
Table 3-28 ISDN 7500B Data Module Option Settings for
Digital-to-Analog Modem Pool Operation
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Position No.:
L 1 :
L 2 :
b = blank, L = Line #
Modem Option Settings. The following procedure is one
method to prepare the AT&T model 2224G modem for operation
in a digital-to-analog modem pool. The procedure is only a
recommended method and may be different if you are using
another type of modem.
1. Connect a data terminal such as a PC to the modem and plug
both the modem and data terminal into an AC outlet.
2. Use the instructions provided with the modem to set all bit-
switches to their default positions; except set the switch 1,
bit 2 to the right.
3. Save all bit-switch settings by unplugging the modem from
the wall outlet and then plugging it back in.
4. Set the data terminal speed to match the modem's default
speed.
5. The modem is now operating in the AT&T command protocol.
Set the default software options:
Type "od"
Press Enter
6.
Set all bit-switches according to Table 3-29.
3-72 Data Adapters
3 3 3 0 0 0 b 0 0 1 0 1 1
0 1 1 1 0 0 0 3 1 0 0 0 0
