Installation
Table 3-27 AT&T 475/476 Printer DIP Switch Settings
Switch 1
DIP 1–Open
DIP 2–Closed
DIP 3–Open
DIP 4–Open
DIP 5–Closed
DIP 6–Closed
DIP 7–Closed
DIP 8–Open
Switch 22
DIP 1–Open
DIP 2–Closed
DIP 3–Closed
DIP 4–Open
Note: Open = off, Closed = on.
Switch 2
DIP 1–Open
DIP 2–Open
DIP 3–Open
DIP 4–Open
DIP 5–Open
DIP 6–Open
DIP 7–Closed
DIP 8–Open
Switch 23
DIP 1–Closed
DIP 2–Open
DIP 3–Open
DIP 4–Open
DIP 5–Closed
DIP 6–Open
The Printer and the PC 3-49
Switch 21
DIP 1–Open
DIP 2–Open
DIP 3–Open
DIP 4–Closed
DIP 5–Open
DIP 6–Open
DIP 7–Open
DIP 8–Closed
Switch 24
DIP 1–Open
DIP 2–Closed
DIP 3–Closed
DIP 4–Open
DIP 5–Open
DIP 6–Closed
DIP 7–Open
DIP 8–Closed
