Installation
Assemble the MLX Telephone or
Console
Before installing an MLX telephone or console, consider the
following:
A 630B Phonemount (not included) is required to mount an
MLX-10 or MLX-10D telephone to the wall.
To connect an adjunct, you must first have a Multi-Function
Module (MFM). (Adjuncts include answering machines, alerts,
and fax machines.) If you are installing an MFM, do it now by
using the procedure in "Install the Multi-Function Module"
earlier in this chapter. After the MFM is installed, go to step 1.
Procedure
1.
Remove or adjust the desk stand (see Figure 57).
MLX telephones are packed fully assembled with the desk
stand in the low position. The angle of any MLX desk
telephone can be adjusted to the high position. If you are wall
mounting an MLX-10 or MLX-10D telephone, you must first
remove the desk stand. To remove the desk stand or adjust
its angle, place the telephone face down on a flat surface and
follow these steps:
Press on the top rear center of the stand to release the
a.
tab(s). Pull the stand toward you and away from the
telephone.
Note: If you have removed the stand to wall mount an
MLX-10 or MLX-10D telephone, set the stand aside and
go to step 2.
To adjust the stand to the high position, insert the tab(s) at
b.
the bottom of the stand into the slot(s).
