System Description
8 display-associated buttons
accommodates one or two Direct Station Selectors (DSSs)
MLX-10D Telephone (see Figure 7)
10 line and feature buttons
desktop or wall-mount
display (2 lines x 24 characters)
8 display-associated buttons
MLX-10 Telephone (see Figure 8)
10 line and feature buttons
desktop or wall-mount

Analog Multiline Telephones

In addition to the MLX telephones, the analog multiline
telephones in Table 1-5 can be connected to the system.
Table 1-5 Analog Multiline Telephones
Model
5-button*
10-button*
34-button*
34-button
Deluxe*
* Vintage telephone; no longer available for sale or lease
1-28 Telephones and Consoles
Description
5-button telephone with membrane. No adjuncts
are supported with this telephone.
10-button telephone with membrane
34-button basic telephone with membrane
Deluxe 34-button telephone with membrane
