Installation

Installation of the MERLIN LEGEND Communications System
involves these equipment areas:
control unit
system wiring
telephones and consoles
Depending on the system's configuration, other equipment, such
as an ISDN 7500B Data Module or a Station Message Detail
Recording (SMDR) printer, can also be connected to the CU.
This chapter tells you how to install the system. Follow the
recommended sequence whenever possible.
Note: You must record each station jack connection and each
station change on the "System Technician's Run Sheet" (see
Appendix L).
Installation 3-1
