AT&T MERLIN LEGEND Installation & Maintenance Manual page 297

Programming Procedures
E&M Signal
Step
1. Display Tie Lines screen
and select E&M Signal
2. Identify tie trunk and save Dial trunk no
entry
if you are programming
more than one tie trunk,
enter the lowest trunk
number.
3. Specify E&M trunk
signaling
For type 1S signaling
For type 1C signaling
For type 5 signaling
PC
Console
LinesTrunks
TIE Lines
E&M Signal
(801-880), ∗ +
slot and port, or
# + logical ID
# + logical ID
F10
Enter
Type 1S
Type 1C
Tpye 5
Tie Trunks
F 4
F 2
F 4
Type trunk no
∗
(801-880), +
slot and port, or
F1
F 2
F 3
4-55
