Programming Procedures
Step
2. Identify DID trunk and
save entry
If you are programming
more than one DID trunk,
enter the lowest trunk
number.
3. Specify disconnect time
(140-2400 ms, in
increments of 10)
4. Save entry and either
program another DID
trunk or exit
To save entry and
specify disconnect
time for another DID
trunk:
If next tie trunk number
is sequential
If next tie trunk number
is not sequential
To save entry and exit
when all entries are
complete
Console
PC
Dial trunk no. Type trunk no.
(801-880), ∗ +
slot and port, or
# + logical ID
Enter
Dial number of
ms: [nnnn] ms: [nnnn]
F9
Next
Repeat step 3 Repeat step 3
E n t e r F10
F 3
Disconnect
Repeat Repeat
steps 2-4 steps 2-4
F10
Enter
F 5
E x i t
E x i t
F 5
DID Trunks
(801-880), ∗ +
slot and port, or
# + logical ID
F10
Type number of
4-65
