Configuring A Static Rpf Peer - 3Com 3C13636 Configuration Manual

3Com Router 3000 Ethernet Family
Configuration Guide
Remove the description
The command for description is optional.
If the local router is also in BGP Peer relation with an MSDP peer, the MSDP peer and
the BGP peer should use the same IP address.

5.2.3 Configuring a Static RPF Peer

Perform the following configuration in MSDP view.
Table 5-3 Configure a static RPF peer
Configure a static RPF peer
Remove the configured static RPF peer
By default, no static RPF peer is configured.
The peer command must be configured before the configuration of static-rpf-peer
command.
If only one MSDP peer is configured via the peer command, the MSDP peer will be
regarded as the static RPF peer.
To configure multiple static RPF peers at the same time, take any of the two methods:
Using rp-policy parameters universally: Multiple static RPF peers take effect at
the same time and SA messages are filtered by the RP addresses contained
according to the configured prefix list. If multiple static RPF peers using the same
rp-policy parameter are configured, any peer that receives an SA message will
forward it to the other peers.
Not using the rp-policy parameter universally: According to the configuration
sequence, only the first static RPF peer whose connection state is UP is activated.
All SA messages from the peer will be received and those from other static RPF
peers will be discarded. Once the activated static RPF peer turns invalid (possibly
out of configuration removed or connection interrupted), the following first static
RPF peer with UP connection state according to the configuration sequence will
assume its role.
Operation
Operation
3Com Corporation
5-5
Chapter 5 MSDP Configuration
Command
undo peer peer-address description
text
Command
static-rpf-peer peer-address [ rp-policy
list ]
undo static-rpf-peer peer-address
