Using The Xmcd Utility - HP Visualize J5000 - Workstation Owner's Manual

Using Your CD Drive
Audio Control for the CD Drive

Using the xmcd Utility

The instructions in the section assume that you are using the HP-UX
10.20 operating system
Enhancements (ACE) for HP-UX 10.20 (June 1999) with the HP CDE
interface. The xmcd utility must also be installed on your system. See the
section "Installing the xmcd Utility" above.
To load and play an audio CD, follow the steps in this procedure.
1. Load the audio CD. See the section "Loading a CD" in this chapter.
2. Insert the headphone plug into the headphone jack located on the
back of your system unit.
3. Double-click on the Audio icon located on your HP CDE control
panel.
Audio Icon
96
and the Workstation
Microphone
Headphone
Line Out
Line In
Additional Core
Chapter 4
