The Boot Console Interface
Displaying the Current Monitor Configuration
Displaying the Current Monitor Configuration
To display the current monitor configuration for your system from the
Configuration Menu of the boot console interface, follow the directions in
"Accessing the Boot Console Interface" earlier in this chapter. Once you
are in the Boot Console Interface Main Menu, type the following
command and press
This places you in the Configuration Menu. From here, type the following
command at the prompt and press
The message on your display is a list of the current graphics adapters
and their monitor types configured for your computer.
Configuration Menu: Enter command > monitor
MONITOR INFORMATION
Path Slot
----------- ----
GRAPHICS(4) 4
GRAPHICS(7) 7
In this example, only GRAPHICS(4) and GRAPHICS(7) are configured. The
monitor type for GRAPHICS(4) is set to type 1, which is a 1280 by 1024
monitor that uses a frequency of 75 Hz.
150
Enter
Main Menu: Enter command> configuration
Configuration Menu: Enter command> monitor
HPA Resolution
---------- ----------
fff6000000 1280x1024
fff4000000 1280x1024
:
:
Enter
Freq Type
---- ----
75Hz 1
72Hz 1
Class
-----
VESA,Double buffered
Chapter 8
