Ultra2 Wide Low-Voltage Differential SCSI Bus
Length
The maximum cable length for an Ultra2 Wide Low-Voltage Differential
SCSI bus is 12 meters. The HP V
meter of this maximum cable length internally. This means that up to 11
meters of cable can be used for connecting external Ultra2 Wide
Low-Voltage Differential SCSI devices to this workstation.
NOTE
When calculating the total Ultra2 Wide Low-Voltage Differential SCSI
cable/bus/trace length used externally, remember to account for cables
connecting external devices together as well as the bus length internal to
those devices.
Do not attach FWD SCSI devices to the LVD SCSI port, or
WARNING
damage will occur.
Chapter 7
SCSI Connections
SCSI Bus Length Constraints
J5000/J7000 system uses 1
ISUALIZE
131
