Assigning Ultra Narrow Single-Ended Scsi Device Ids - HP Visualize J5000 - Workstation Owner's Manual

ctl 3 10/2/3/0.7.0
ba 4 10/4
ba 5 10/6
graphics 1 10/6/7/0
processor 0 32
processor 1 34
memory 0 49
Assigning Ultra Narrow Single-Ended SCSI Device
IDs
You can determine which Ultra Narrow Single-Ended SCSI (NSE SCSI)
devices are currently in use by reviewing the output from the ioscan
command discussed above and looking under the "H/W Path" heading.
The entry 10/0/15/0 is the built-in Ultra Narrow Single-Ended SCSI
bus. For devices connected to the built-in Ultra Narrow Single-Ended
SCSI bus, such as disks, the number between the two decimals and after
the third "/" in the hardware path specifies the SCSI ID for that device.
For example, a hardware path of 10/0/15/0.2.0 specifies a NSE SCSI
device at SCSI ID 2. Here is the break down of the hardware path:
CAUTION Do not use SCSI device ID 7 for any device. It is reserved for the built-in
SCSI bus controller.
Chapter 7
sctl CLAIMED
lba CLAIMED
lba CLAIMED
graph3 CLAIMED
processor CLAIMED
processor CLAIMED
memory CLAIMED
SCSI device 10/0/15/0.2.0
NSE SCSI 10/0/15/0.2.0
SCSI ID 2 10/0/15/0.2.0
Assigning SCSI Device IDs
DEVICE Initiator
BUS_NEXUS PCI Bus Bridge - lba
BUS_NEXUS PCI Bus Bridge - lba
INTERFACE PCI(103c1008)
PROCESSOR Processor
PROCESSOR Processor
MEMORY Memory
SCSI Connections
133
