HP Visualize J5000 - Workstation Owner's Manual page 127

HP offers the following SCSI cables for connecting externally connected
devices to the system Ultra2 Wide Low-Voltage Differential port:
Table 7-3 Ultra2 Wide Low-Voltage Differential SCSI Cables
CAUTION SCSI cables approved by HP are designed to function within the SCSI
tolerances for HP devices. Use of other cables can result in significant
problems with system operation.
Always use the shortest possible cable(s) for your configuration.
NOTE See "SCSI Bus Length Constraints" later in this chapter to determine
the total length of your cables.
Chapter 7
Cable Cable
Number Length
C2978A 0.5m
C2911B 1.0m
C2979A 1.5m
C2924B 2.5m
C2361A 1.0m
C2362A 2.5m
C2365A 5.0m
C2363A 10.0m
Description
68-pin HDTS (High-Density Thumbscrew)
to 68-pin HDTS
68-pin VHDCI (Very High Density Cabled
Interconnect) to 68-pin HDTS
SCSI Connections
SCSI Restrictions
127
