Page 5: Table Of Contents
Keyboard Connectors ........25 HP Parallel I/O Connector ........25 802.3 Network Connectors .
Page 6 Contents Reinstalling the Cover Panels ....... 46 Installing Memory ......... . 47 Installing DIMMs .
Page 7 Contents The CD Drive ..........89 CD Media .
Page 8 Contents Operating the Floppy Drive ........117 Formatting a New Diskette .
Page 9 Contents Searching for Bootable Media ....... . .143 Resetting Your Computer ........144 Displaying and Setting Paths .
Page 10 Contents A. Safety and Regulatory Statements Declaration of Conformity ........178 Emissions Regulations .
Page 11: Installation Notice
Safety and Regulatory Statements See Appendix A , “Safety and Regulatory Statements,” on page 177 for the safety and regulatory statements that apply to the HP V Class and J7 Class computer. Installation Notice Products designated in the applicable Hewlett-Packard price list as customer-installable can be installed by computer-knowledgeable customers who carefully read and follow the instructions provided.
Page 12: Related Manuals
The revision history for each edition of the manual is listed below: Edition Revision History E0299 First Printing Problems, Questions, and Suggestions If you have any problems or questions with our hardware, software, or documentation, please contact either your HP Response Center or your local HP representative.
Page 13: Documentation Conventions
Documentation Conventions Unless otherwise noted in the text, this guide uses the following symbolic conventions. Table 1 Documentation Conventions user-supplied values screen display Enter Italic words or characters in syntax and command descriptions represent “conceptual variables”— whose values are indicated by the current context and which you must supply.
Page 14 Electrostatic Discharge (ESD) Precautions Electrostatic discharges (static electricity) can damage the integrated circuits on printed circuit boards and other internal devices. To prevent such damage from occurring, observe the following precautions during board unpacking and installation: • Stand on a static-free mat. •...
Page 15: System Overview
System Overview This chapter introduces the HP V J5xxx and J7xxx computers. ISUALIZE Its purpose is to familiarize you with your computer and its controls and indicators.
Page 16: System Requirements
J5xxx’s motherboard; the J7xxx has four: Figure 1-1 HP V J5xxx /J7xxx Processor-Count Difference ISUALIZE Processors with integral turbocoolers J5xxx J7xxx Instructions in this chapter assume that you are using the HP-UX 10.20 or HP-UX 11.0 operating system. Chapter 1...
Page 17: Product Description
440MHz PA8500 microprocessors with 0.5MB on-chip instruction cache and 1.0MB on-chip data cache. HP-UX 10.20 HP-UX 11.0 HP CDE graphical user interface Source- and binary-code compatible with the C-Class and J-Class product families List of compatible monitors: • 19-inch, 1280 1024 color monitor •...
Page 18 System Overview Product Description Table 1-1 HP V ISUALIZE Computer Feature Main Memory Internal Storage Devices Standard Network Standard I/O J5 Class and J7 Class Features Description Using 256-MB DIMMs: • J5xxx: Up to 2GB in 8 slots • J7xxx: Up to 4GB in 16 slots Using 512-MB DIMMs: •...
Page 19 Table 1-1 HP V ISUALIZE Computer Feature PCI (Peripheral Connect Interface) slots Keyboard Mouse Chapter 1 J5 Class and J7 Class Features Description Eight 64-bit slots in the following arrangement: 1. 5V, 33MHz, bus 1, top slot (power only) 2. 5V, 33MHz, bus 2 3.
Page 20: System Unit, Front View
System Overview System Unit, Front View System Unit, Front View Before powering on your system, you should become familiar with the system unit controls: Figure 1-2 HP V ISUALIZE Floppy Drive or DDS Drive Bay Power Switch 2-line, 16-character LCD...
Page 21: System Lcd
System LCD The Liquid Crystal Display (LCD) is located on the left side of the front panel. The LCD displays messages about the state of the system, including Troubleshooting chapter for more details). The following symbols appear in the LCD, representing the different system activities shown: Figure 1-3 LCD Symbols System Power Switch...
Page 22: System Unit Rear Panel Connectors
• Audio connectors (line in, line out, microphone and headphones) • USB keyboard and mouse connectors • HP parallel Centronics I/O connector • 802.3 TP (Twisted Pair) LAN connector • Two RS-232C serial I/O connectors • Narrow Single-Ended (SE) SCSI connector •...
Page 23 The illustration below shows the locations of the connectors on the system unit’s rear panel. Figure 1-4 System Unit Rear Panel Connectors Power Supply Interlock screw (Torx T-15) RS-232 Narrow SE SCSI Wide LVD SCSI AC Power (Auto-sensing) I/O Slots The two T-15 thumbscrews in the upper corners of the rear panel are the keys to opening the machine: removing these two screws allows the top panel to be removed, which in turn allows the left and right side panels...
Page 24: Audio Connectors
System Overview System Unit Rear Panel Connectors Turning the power off with the power switch executes a clean shutdown, but disengaging the power supply does not, so remember to power down with the power switch! Audio Connectors Your computer has audio input and -output capability through an internal speaker, as well as external input and output connectors on the rear panel (see diagram of entire rear panel above, plus the close-up of the audio connectors, below).
Page 25: Keyboard Connectors
(either connector can be used for either device). Consult the documentation that accompanies each input device for speciﬁc information concerning its use. Note that older non-USB keyboards (PS-2 and HP-HIL keyboards) cannot be used with the J5xxx and J7xxx. HP Parallel I/O Connector The 25-pin HP Parallel I/O interface uses Centronics interface protocols to support peripheral devices such as printers and plotters.
Page 26: Rs-232C Serial Input/Output Connectors
System Overview System Unit Rear Panel Connectors RS-232C Serial Input/Output Connectors You can attach peripheral devices to the RS-232C Serial Input/Output (SIO) ports on this computer. Peripheral devices include printers, plotters, modems, and scanners. Consult the documentation that accompanies each pointing or peripheral device for speciﬁc information concerning its use.
Page 27: Power Cord Connectors
Power Cord Connectors Plug the workstation’s power cord into the power cord connector to provide AC power to the system. Note that the HP V J7xxx have different types of power cords, because of their differing power requirements:...
Page 28: Keyboard And Mouse
System Overview Keyboard and Mouse Keyboard and Mouse At this printing, only the HP three-button USB mouse is supported as a pointing device for the J5xxx and J7xxx. For general information on using three-button mice and on the various cursor shapes associated with different areas of HP CDE while using a mouse or other pointing device, see Using Your HP Workstation.
Page 29: Operating System Overview
Managing Systems and Workgroups to conﬁgure your kernel as appropriate for your set of hardware and peripheral devices. If you have any questions about Instant Ignition, refer to HP-UX System Administration Tasks for more information. Chapter 1...
Page 30: Powering Up Your System
At this point, there are two possibilities: • Your computer has been “ignited;” that is, the HP’s Instant Ignition process has installed the operating system already. In this case, when you power up the computer, you will be presented with a series of questions asking you the machine’s hostname, IP address, subnet...
Page 31: Getting Required Information
Getting Required Information The start-up procedure for your workstation will require you to supply the following information. Please have this information available before you turn the workstation on for the ﬁrst time. NOTE If you are not the system administrator for your workstation, and therefore do not know the information, ask your system administrator.
Page 32 System Overview Powering Up Your System • Optional font server parameters You need to supply these parameters if you want the workstation to obtain its fonts from a network server. Ask your system administrator if you need to conﬁgure these parameters. Table 1-5 Font-Server Parameters Font server name...
Page 33: Turning On The Power
CDE login screen. 7. Log into your ﬁrst CDE session as root. For information on logging into CDE, see the Common Desktop Environment User’s Guide. Chapter 1 System Overview Powering Up Your System...
Page 34: Documentation
System Overview Powering Up Your System NOTE You must log into the ﬁrst session as root. This is because the system contains no other user accounts. Once you are done with system conﬁguration, including the creation of other users’ accounts via SAM (the System Administration Manager), you should log out as superuser and log back in as one of the other users.
Page 35: Monitors
System Overview Monitors Monitors You can use one of the following HP monitors with your computer: • 19-inch, 1280 1024 color monitor (A4575A) • 19-inch, 1600 1200 color monitor (A4575A) • 21-inch, 1280 1024 color monitor (A4576A) • 21-inch, 1600 1200 color monitor (A4576A) Before using your monitor, you should become familiar with its controls, connectors and indicators.
Page 36 System Overview Monitors After a few seconds of analyzing your hardware and software conﬁgurations, the splash screen disappears, and another window appears, which offers access to the various administration tasks: Figure 1-8 SAM’s Main Menu Double-click the “Display” icon, and something like the following appears (of course, the actual devices on your machine are likely to be different): Figure 1-9 X Server Conﬁguration Screen...
Page 37 System Overview Monitors Double-clicking on any of the icons that represent graphics devices (or single-clicking and then selecting under the menu) will Describe... Actions cause a monitor-description window to appear; for example: Figure 1-10 Monitor Description Window Other options under the menu allow you to identify the physical Actions monitor associated with the logical monitor (by making the screen image...
Page 38 System Overview Monitors Figure 1-11 X-Window Screen Description Window As before, other options under the menu allow you to identify the Actions physical monitor associated with the X-screen deﬁnition (again, by making the screen image blink), and to change the default visual, screen options, server options, etc.
Page 39: Changing Your Computer's Hardware Conﬁguration
Changing Your Computer’s Hardware Conﬁguration This chapter describes the procedures required to change your computer’s hardware conﬁguration.
Page 40 Changing Your Computer’s Hardware Conﬁguration The instructions in this chapter assume you are using the HP-UX 10.20 or 11.0 operating system and the HP CDE interface. CAUTION When installing internal devices, always wear a properly grounded wrist strap to avoid damaging components with electrostatic discharge (static electricity).
Page 41: Opening The System Unit
Opening the System Unit Some hardware-conﬁguration operations, like installing and removing hard disk drives, can be done simply by opening the door on the front of the unit; the disk drives are accessible through the open door. Other operations require a bit more access to the interior of the computer, so more panels will need to be removed.
Page 42: Removing The Front Panel
Changing Your Computer’s Hardware Conﬁguration Opening the System Unit Removing the Front Panel The front panel must be removed in order to install a CD drive, a DDS tape drive, or a ﬂoppy drive—see their respective sections later in this chapter for detailed instructions on the installation process for each type of device.
Page 43 Figure 2-2 System Unit with Front Cover Panel Removed Floppy Drive or DDS Drive Bay Panel hinge hole LCD Connector Power switch System LCD Removable hard disk drives Panel hinge holes Once the front panel has been removed, a CD drive, DDS drive, and/or a ﬂoppy drive can be installed or removed.
Page 44: Opening The Top Cover
Changing Your Computer’s Hardware Conﬁguration Opening the System Unit Opening the Top Cover To open the top cover of the unit—to install or remove a removable-media drive (i.e., a CD drive, a DDS tape drive, or a ﬂoppy drive), DIMMs, or I/O cards, for example, or for other access to the inside of the unit—follow these steps: 1.
Page 45: Removing The Left And/Or Right Panels
Changing Your Computer’s Hardware Conﬁguration Opening the System Unit Figure 2-4 Removing the Top and Side Panels Removing the Left and/or Right Panels In order to remove the left and/or right panels, you must ﬁrst remove the top panel, as described above. Then, the left and right panels are free to tip out and away from the unit.
Page 46: Reinstalling The Cover Panels
Changing Your Computer’s Hardware Conﬁguration Opening the System Unit Reinstalling the Cover Panels To replace the cover panels once you’ve taken them off, perform the following steps: 1. Place the left- and right-side panels into their grooves in the bottom edges of the left and right sides of the chassis, and then press the tops of the side panels together ﬁrmly.
Page 47: Installing Memory
Installing Memory This section contains information regarding the installation of additional memory. However, before continuing with this section, please take time to read the following list of considerations: • Use the procedure described in the chapter “The Boot Console Interface” to determine the current memory conﬁguration for your computer.
Page 48: Installing Dimms
Changing Your Computer’s Hardware Conﬁguration Installing Memory order indicated in the right illustration above (or on the label on the air guide). For details on the mechanics of inserting DIMMs, see the following pages. • When you have ﬁnished installing the additional DIMMs, use the Boot Console Interface to verify that the computer recognizes them.
Page 49 so it must be removed before installing or removing DIMMs. Before the air guide is removed, the open left side of the J7xxx looks like this: Figure 2-7 The J7xxx’s Open Left Side Before Removing Air Guide Support Bar Air Guide Screws Support Bar Remove the four screws that secure the air guide to the support bars.
Page 50 Changing Your Computer’s Hardware Conﬁguration Installing Memory After the air guide is removed, the open left side of the J7xxx looks like this: Figure 2-8 The J7xxx’s Open Left Side After Removing Air Guide DIMM Slots (16 total) Chapter 2...
Page 51 2. Install DIMMs in the order indicated in Figure 2-5 on page 47, or on the label on the ﬂoor of the chassis (the J7xxx requires DIMMs to be installed in pairs of the same size). Make sure the DIMM-removal tabs are angled out—away from each other.
Page 52 Changing Your Computer’s Hardware Conﬁguration Installing Memory 4. Re-install the air guide with the four screws removed earlier (so it again looks like Figure 2-7 on page 49), close the system unit and reconnect all cables. 5. Verify that this installation was successful by following the steps in “Displaying the Memory Conﬁguration”...
Page 53: Installing A Pci-Type I/O Board
3.3-volt or 5-volt cards (or both; these are called “universal” cards), and they can also be 32-bit or 64-bit cards, and 33MHz or 66MHz. The graphics boards supported by the J5 Class and J7 Class computers are the HP V Pro and the HP V Pro. While ISUALIZE ISUALIZE these are universal cards and will work in any slot, they should be used in slots 4 or 7 to obtain optimal performance.
Page 54 The J5xxx and J7xxx supply approximately 264 watts of power to the PCI slots. Thus, if you use three HP V simultaneously (in Slots 7, 4, and 2), as in the HP V conﬁguration, there are some power constraints imposed on the remaining slots.
Page 55 The illustration below shows the physical layout of the PCI slots: Figure 2-13 PCI Slots in a J5 Class and J7 Class Power Supply PCI Card Retaining Clip PCI Card Slots (Slot 7 is the primary graphics slot; Slot 4 is the secondary) PCI Card Cooling Fan...
Page 56 Changing Your Computer’s Hardware Conﬁguration Installing a PCI-Type I/O Board 4. Remove the screw that secures the ﬁller plate corresponding to the slot into which you are installing the PCI card, and then remove the ﬁller plate itself, saving it for future use. The ﬁller plate must be removed in order for the PCI card’s connectors to be accessible from outside the chassis.
Page 57: Changing Your Monitor Type
Changing Your Computer’s Hardware Conﬁguration Changing Your Monitor Type Your system ships from the factory preset to use a monitor with a speciﬁc resolution and frequency. If you replace you monitor with a different type, you must reconﬁgure your computer to support it. There are two ways to conﬁgure your computer to support a different monitor type.
Page 58: Cd Drive Installation
Changing Your Computer’s Hardware Conﬁguration CD Drive Installation CD Drive Installation To install a CD drive, follow the steps below: 1. Using standard static-suppression practices (described in the Preface of this document), remove the computer’s front panel, as described in“Removing the Front Panel” on page 42, and top cover, as described in “Opening the Top Cover”...
Page 59 Figure 2-15 Removing the CD Drive Filler Panel Filler panel must be removed before installing the CD drive 4. Unpack the CD drive, avoiding shocks both mechanical and electrical. That is, never let it drop onto the ﬂoor or even onto a desk; always set it down gently.
Page 60 Changing Your Computer’s Hardware Conﬁguration CD Drive Installation Figure 2-16 Inserting the CD Drive Into its Bracket CD Drive CD Drive Bracket The assembly should now appear as follows: Figure 2-17 The CD Drive in its Bracket Secure the CD drive assembly by inserting screws here Chapter 2...
Page 61 Changing Your Computer’s Hardware Conﬁguration 6. Slide the bracket, now containing the CD drive, halfway into the CD drive bay. 7. Connect the power, audio, and ribbon cables into their respective connectors, taking care to fold the ribbon cable neatly, so it won’t be crushed during insertion.
Page 62: Verifying The Cd Drive Operation
Changing Your Computer’s Hardware Conﬁguration CD Drive Installation Verifying the CD Drive Operation To verify that your workstation can communicate with the CD drive, follow these steps: 1. In a terminal window, enter the following command: /usr/sbin/ioscan -d sdisk After a few moments the ioscan utility lists all of the SCSI I/O devices it could ﬁnd.
Page 63: Dds Drive Installation
DDS Drive Installation NOTE Before opening the system unit to install a DDS drive, determine the SCSI IDs currently in use on your computer, so as to avoid SCSI ID conﬂicts. To install a DDS drive, follow the steps below: 1.
Page 64 Changing Your Computer’s Hardware Conﬁguration DDS Drive Installation Figure 2-19 Removing the DDS/Floppy Drive Bracket 4. Install the DDS drive into the bracket: the drive itself must be inserted into the DDS drive bracket, and secured by four Torx T-10 screws (two on each side).
Page 65: Verifying The Dds Tape Drive Operation
Changing Your Computer’s Hardware Conﬁguration 7. Slide the bracket, now containing the DDS drive, into the DDS drive bay. Observing—and manipulating, if necessary—from above, make sure the drive’s ribbon cable folds neatly and compactly, and its ferrite bead (the elongated loop of iron-containing material) does not hinder the folding process.
Page 66: Floppy Drive Installation
Changing Your Computer’s Hardware Conﬁguration Floppy Drive Installation Floppy Drive Installation To install a PC ﬂoppy drive into the J5 Class and J7 Class, follow the steps below: 1. Using standard static-suppression practices (described in the Preface to this document), remove the computer’s front panel, as described earlier in “Removing the Front Panel”...
Page 67 3. Remove the ﬁller panels from the DDS/ﬂoppy drive bracket by removing the screws and sliding the panels back and then up, as indicated in the illustration below. Save the larger of the two ﬁller panels for future use; the smaller of the two will be re-installed after the ﬂoppy drive itself has been installed onto the bracket.
Page 68 Changing Your Computer’s Hardware Conﬁguration Floppy Drive Installation Figure 2-23 Floppy Drive, Filler Installed into the DDS/Floppy Drive Bracket 6. Connect the power cable and the data (ribbon) cable to the ﬂoppy drive. 7. Slide the bracket, now containing the ﬂoppy drive, into the ﬂoppy drive bay.
Page 69: Verifying The Floppy Drive Conﬁguration
Changing Your Computer’s Hardware Conﬁguration Verifying the Floppy Drive Conﬁguration To verify that your workstation can communicate with the ﬂoppy drive, use the ioscan command in a terminal window to see which devices are currently in use on your system. Note that you will have to be superuser or root to use the ioscan command.
Page 70 Changing Your Computer’s Hardware Conﬁguration Floppy Drive Installation Chapter 2...
Page 71: Hot-Pluggable Hard Disk Drives
Hot-Pluggable Hard Disk Drives This chapter describes the hot-pluggable hard disk drives, and how to install and remove them.
Page 72: The Disk Drives
Hot-Pluggable Hard Disk Drives The Disk Drives The Disk Drives When reconﬁguring your computer’s internal hardware, always wear a properly grounded wrist strap to avoid damaging components. Figure 3-1 System Unit with Front-Panel Door Open Floppy Drive or DDS Drive Bay Power switch System LCD Interchangeable...
Page 73 Hot-Pluggable Hard Disk Drives The Disk Drives positions in the slots, not switches on the drives themselves, deﬁne the SCSI address for each drive. These addresses are labelled on the chassis. Finally, these hard drives are hot-pluggable: that is, you do not need to power down the entire machine to remove or insert a hard disk drive.
Page 74: Removing A Hard Disk Drive
Hot-Pluggable Hard Disk Drives The Disk Drives Removing a Hard Disk Drive The instructions for removing a disk drive from the J5 Class and J7 Class are printed on the front panel, and are visible when the panel door is opened, as shown in the detail below. CAUTION If you are removing a hard disk drive while the system is running, you must perform the operations outlined in “The Hot-Plug Procedure”...
Page 75: Putting A Disk Drive Into Its Tray
3. Wait about 30 seconds for the drive to spin down (handling of a disk drive while it is still spinning can cause disk damage and/or loss of data). 4. Carefully pull the drive straight out. If you also need to remove the disk drive from the disk-drive tray—to replace a faulty drive, for example—remove the four screws that secure the drive to the tray.
Page 76 Hot-Pluggable Hard Disk Drives The Disk Drives drive in it, the four screws required to secure the drive to the tray are stored in two tabs on the tray (see illustration below). Remove these four screws from the storage tabs. Figure 3-3 Installing a Hard Disk Drive into its Tray Screw-storage tab...
Page 77: Inserting A Disk Drive
Inserting a Disk Drive To insert a drive, the procedure is virtually identical to the “removing” steps above, except in the reverse order: 1. Carefully push the drive, which is already in its tray, straight into the desired slot, making sure the drive-tray’s handle is pulled away from the front surface of the tray.
Page 78: The Hot-Plug Process
“hot-swappable.” Hot swapping happens at the device level; that is, a hot-swappable device manages insertion/removal on its own without assistance from HP-UX commands. The disk drives in the J5xxx and J7xxx are not hot-swappable; they are merely hot-pluggable. Thus, a manual software procedure must be done in order to safely remove or insert disk drives while the system is running.
Page 79: Hot-Plug Example
because manipulation of the LVM requires specialized knowledge that only experienced system administrators are expected to have (see below for details). Hot-Plug Example The following example describes a particular system problem where the solution is to replace a hot-plug disk module. Volume group /dev/vg00 contains the three disks, with the logical volume conﬁguration as shown: Table 3-1...
Page 80 3. The replacement disk must be the same product ID as the replaced one. NOTE HP often uses different manufacturers for disks having the same product number. The hot-plug manual procedure will not update the disk driver’s internal information to that of the replaced disk.
Page 81: The Hot-Plug Procedure
The Hot-Plug Procedure These are the steps required to properly hot-plug a disk drive: Step 1 • Check if the LVM found the physical volume to be defective when the volume group was activated. • The “vgchange -ey” would have printed the following message on the console: WARNING: VGCHANGE:WARNING: COULDN’T ATTACH TO THE VOLUME GROUP...
Page 82 Hot-Pluggable Hard Disk Drives The Hot-Plug Process Step 2 • Reduce any logical volumes that have mirror copies on the faulty disk so that they no longer mirror onto that disk (note the -A n option): lvreduce -m 0 -A n LV name /dev/dsk/cXtXdX (for 1-way mirroring) lvreduce -m 1 -A n LV name /dev/dsk/cXtXdX (for 2 way mirroring)
Page 83 Step 6 • If this disk is not a mirror of a root disk, then skip this step. • Run the mkboot command. For our example: mkboot /dev/rdsk/c2t4d0 • Run lvlnboot -R to relink the replaced disk into the Boot Data Reserved Area of all the Physical Volumes in the Volume Group.
Page 84: Checking The Scsi Ids
Hot-Pluggable Hard Disk Drives Checking the SCSI IDs Checking the SCSI IDs To determine which SCSI IDs are currently in use on your system, use the ioscan command in a terminal window. Note that you will need to be superuser (root) in order to use the ioscan command. Here are the steps necessary for determining SCSI IDs: 1.
Page 85: Using Device Files
10/4 10/6 graphics 10/6/7/0 processor processor memory 2. You can determine which SCSI IDs are currently in use by looking under the “H/W Path” heading. In the example display, the H/W Path for the built-in SCSI interface is 8/16/5. For devices connected to the built-in SCSI bus, such as disks, the fourth number is the SCSI ID for that device.
Page 86 Hot-Pluggable Hard Disk Drives Checking the SCSI IDs . A window opens with a list of information for the disk Information drive, including the device ﬁles. Chapter 3...
Page 87: Using Your Cd Drive
Using Your CD Drive...
Page 88: Operating The Cd Drive
CD-RW disks (also called “CD-RAM” because they are rewritable). Thus, since not all CDs are ROMs any longer, that portion of the term has been dropped. The CD drives also are multisession-capable. Note that this chapter assumes you are running HP-UX 10.20 or 11.0. Chapter 4...
Page 89: The Cd Drive
The CD Drive The CD drive is a random-access read-only mass storage device that uses removable CDs. The drive supports the ISO 9660 and High Sierra format standards. You can access information from the drive like any other disk drive, except that you cannot write to the drive.
Page 90 Using Your CD Drive Operating the CD Drive Table 4-1 CD Drive Controls and Indicators Control/Feature Busy Indicator Eject Button Emergency Eject Hole CD Tray NOTE There is neither a volume control nor a headphone jack on the front of the CD drive.
Page 91: Cd Media
CD Media CDs are 120mm (4.7 in.) in diameter, and use one data surface with a capacity of approximately 600 megabytes. The data surface contains pits and ﬂat spots arranged in a continuous spiral track, which is read at a constant linear speed (and hence a variable rotational speed).
Page 92: Loading And Unloading A Cd In The Disk Tray
Using Your CD Drive Operating the CD Drive Loading and Unloading a CD in the disk Tray This subsection describes how to load or unload a CD in the CD drive. Loading a CD This CD drive has an automatic loading/ejecting feature. To load a disk in the CD drive, follow these steps: 1.
Page 93: Audio Control For The Cd Drive
Hewlett-Packard, and it is one of many audio controllers for CD drives available in the marketplace. Since the xmcd utility is not a part of HP-UX, you will need to download it off the web using your web browser and this URL: http://metalab.unc.edu/tkan/xmcd...
Page 94: Using The Xmcd Utility
Audio Control for the CD Drive Using the xmcd Utility The instructions in the section assume that you are using the HP-UX 10.20 or 11.0 operating system with the HP CDE interface. The xmcd utility must also be installed on your system. See the section “Installing the xmcd Utility”...
Page 95 4. Click on the Monitoring checkbox in the Audio window to select it. Then select the Output menu and click on the Headphones item in the menu list. In the File menu select the item Close, this will close the Audio window and save your settings. 5.
Page 96: Mounting And Unmounting A Cd
Administration Manager) if you prefer; the instructions for using SAM to mount and unmount CDs are in the next section. If your workstation is running HP CDE, follow these instructions to mount and unmount a CD as a ﬁle system. If you’re using something other than HP CDE, use the instructions for mounting and unmounting a CD that come with that product.
Page 97: Mounting A Cd Using Sam
Use the following procedure to mount a CD: • Log in as root. If you need information on logging in or setting up a user account, see Using Your HP Workstation. • Load the CD into the disk tray and push the Eject button, or gently push the tray a short distance into the drive;...
Page 98: Unmounting A Cd Using Sam
1. Log in as root. If you need information on logging in or setting up a user account, see Using Your HP Workstation. 2. In a terminal window, enter the following command: The System Administration Manager window opens, showing several window opens with a list of unused Select a Disk to Add...
Page 99 icons, one of which looks like this: 3. Double-click on Disks and File Systems -> window opens, showing several more icons, one of which look like this: 4. Double-click on File Systems the following screen message appears brieﬂy: Scanning the system’s hardware... The File Systems window opens, containing a list of drives currently conﬁgured on this system.
Page 100 Using Your CD Drive Mounting and Unmounting a CD Chapter 4...
Page 101: Using Your Digital Data Storage (Dds) Tape Drive
Using Your Digital Data Storage (DDS) Tape Drive...
Page 102 Using Your Digital Data Storage (DDS) Tape Drive This chapter describes how to use the optional Digital Data Storage (DDS) tape drive. It also describes how to maintain and care for the drive. CAUTION Use only data cassettes labeled DDS (Digital Data Storage). Never use audio cassettes labeled DAT (Digital Audio Tape) in your DDS-format drive.
Page 103: Dds Tape Drive And Cassette Descriptions
Using Your Digital Data Storage (DDS) Tape Drive DDS Tape Drive and Cassette Descriptions This section describes basic information needed for using your DDS tape drive and data cassettes. The DDS Drive The DDS-3 tape drive has a 3.5-inch form factor and a narrow single-ended SCSI interface.
Page 104 Using Your Digital Data Storage (DDS) Tape Drive DDS Tape Drive and Cassette Descriptions With compression, the capacities double: Table 5-2 Controls and Indicators The ﬁgures below show the LEDs and eject button of the DDS-format tape drives. Figure 5-1 DDS-3 Drive Controls and Indicators Left (green) LED LEDs...
Page 105 Figure 5-2 DDS3 Tape Drive LED Display Codes Left Right (green) (amber) Legend: LED Warning Conditions The following sections describe actions to take if the LEDs indicate a warning condition. Self-Test Failure If the LEDs display the self-test (failure) signal, a fault was diagnosed during the self tests.
Page 106: Data Cassettes
Data Cassettes Media Life HP DDS data cassettes are currently speciﬁed to 2000 passes over any part of the tape under optimal environmental conditions (50% relative humidity, 22 degrees C). During a tape operation, any one area of the tape may have multiple passes over the heads.
Page 107 Caution signal is displayed on the LED. NOTE Only use HP Cleaning Cassettes (HP92283K) to clean the tape heads. Do not use swabs or other means of cleaning the tape heads. Follow this procedure to clean the tape heads: 1.
Page 108: Setting The Write-Protect Tab On A Data Cassette
Using Your Digital Data Storage (DDS) Tape Drive DDS Tape Drive and Cassette Descriptions Setting the Write-Protect Tab on a Data Cassette You can only store or change information on a data cassette when the write-protect tab is in the write position. So, before trying to write to the data cassette, make sure that the write-protect tab is in the Write position, as shown below.
Page 109: Operating The Dds Tape Drive
Using Your Digital Data Storage (DDS) Tape Drive Operating the DDS Tape Drive Loading and Unloading a Data Cassette Follow these steps to load and unload a data cassette from the DDS tape drive: • Insert the data cassette into the drive, the hinged door ﬁrst, and the write-protect tab visible on the right side of the trailing edge.
Page 110: Archiving Data
Archiving Data This section describes how to transfer data to and from a DDS-format data cassette (saving and restoring) using the HP-UX tar command and your tape drive’s device ﬁle. The tar command allows you to save ﬁles to a data cassette, restore ﬁles from a data cassette to your system, or list the ﬁles on your data cassette.
Page 111: Restoring Files From A Data Cassette To Your System
Using Your Digital Data Storage (DDS) Tape Drive Restoring Files from a Data Cassette to Your System Use the following instructions to restore ﬁles from a data cassette to your system: 1. Load the data cassette into the tape drive. 2.
Page 112: Further Command Information
To order Hewlett-Packard data cassettes and cleaning cassettes for use in your DDS tape drive, use the following order numbers: 1. HP 92283A: Box of ﬁve 60-meter DDS data cassettes 2. HP 92283B: Box of ﬁve 90-meter DDS data cassettes 3.
Page 113: Using Your 3.5-Inch Floppy Disk Drive
Using Your 3.5-Inch Floppy Disk Drive This chapter describes how to perform tasks that allow you to archive to or transfer data from the 3.5-inch ﬂoppy disk drive.
Page 114 Using Your 3.5-Inch Floppy Disk Drive The instructions in this chapter assume you are using the HP-UX 10.20 or 11.0 operating system, and the HP CDE interface. NOTE When examples of user input are given in this chapter, enter them at the command-line prompt in an HP CDE terminal window or HP-UX shell.
Page 115: Using The Floppy Diskette
Using the Floppy Diskette This section describes basic information needed for using your ﬂoppy diskettes. Setting the Write-Protect Tab on a Diskette You can only store or change information on a diskette when the write-protect tab is in the write position. So, before trying to write to the diskette, make sure that the write-protect tab is in the write position, as shown below.
Page 116: Inserting And Removing A Diskette
Using Your 3.5-Inch Floppy Disk Drive Using the Floppy Diskette Inserting and Removing a Diskette Follow these steps to insert and remove a diskette from the ﬂoppy disk drive. 1. Insert the diskette into the drive, sliding-door edge ﬁrst, label side up. 2.
Page 117: Operating The Floppy Drive
Transferring Data To and From a Floppy Diskette This section describes how to transfer data to and from your ﬂoppy diskette (saving and restoring) using the HP-UX tar command with your ﬂoppy drive’s device ﬁle. You need to set the write-protect tab to the write position to transfer data to the diskette.
Page 118 Using Your 3.5-Inch Floppy Disk Drive Operating the Floppy Drive 2. Load the formatted ﬂoppy diskette into the disk drive. 3. Type the following in a terminal window at the prompt and press Enter tar -cvf deviceﬁle pathname where deviceﬁle is the device ﬁle as listed by SAM and pathname is the path name of the ﬁle or directory containing ﬁles that you want to write to the diskette.
Page 119: Listing The Files On A Floppy Diskette
ﬂoppy from the drive. For more information about how to mount and unmount the ﬂoppy drive, see the man page for mount, or the manual Using HP-UX. For more information on copying data to or from your system to other media, including your ﬂoppy diskette, refer to the cpio man page by...
Page 120: Conﬁguring The Floppy Driver
Conﬁguring the Floppy Driver If you reload software or rebuild the Instant Ignition system on your computer, you need to reconﬁgure the HP-UX kernel to add the ﬂoppy disk driver. Use the SAM utility to add the sioflop and siofdc ﬂexible disk drivers and build a new HP-UX kernel.
Page 121: Scsi Connections
SCSI Connections This chapter provides information about connecting Small Computer System Interface (SCSI) devices to an HP V J5 Class and J7 ISUALIZE Class computer.
Page 122 SCSI Connections The instructions in this chapter assume you are using HP-UX 10.20 or 11.0 operating system with HP CDE. NOTE When attaching external SCSI devices, be sure to terminate the last device on the external SCSI bus. Note that these terminators were shipped with your system.
Page 123: Scsi Bus Differences
Up to 80 Low-Voltage Mbytes/sec Differential 1. Address 7 is reserved for host controller use on all buses. 2. This information is speciﬁc to the HP Visualize B1000/C3000 and J5 Class and J7 Class computers. Chapter 7 Data Bus Available...
Page 124: Scsi Restrictions
Low-Voltage Differential SCSI bus supports only 15 devices because address 7 is reserved by the system. Cables Only SCSI cables approved by HP can be used to connect your workstation to any SCSI devices. HP offers the following SCSI cables for Ultra Narrow Single-Ended SCSI devices:...
Page 125 C2365A C2363A CAUTION SCSI cables approved by HP are designed to function within the SCSI tolerances for HP devices. Use of other cables can result in signiﬁcant problems with system operation. Always use the shortest possible cable(s) for your conﬁguration.
Page 126: Terminators
(LVD) SCSI buses have been qualiﬁed as SCSI devices which meet NSE and LVD speciﬁcations. Contact your local HP sales representative for a current list of SCSI devices supported by HP for use on the Ultra Narrow Single-Ended and Ultra2 Wide Low-Voltage Differential SCSI buses.
Page 127 Narrow Single-Ended or the Ultra2 Wide Low-Voltage Differential SCSI bus on this system, they must adhere to cabling, termination and bus length restrictions discussed in this chapter to assure functionality of the SCSI busses. Because Ultra2 Wide Low-Voltage Differential SCSI is a relatively new technology, there can be products which are advertised as LVD compliant, but may not meet LVD speciﬁcations.
Page 128: Scsi Bus Length Constraints
SCSI bus. Ultra Narrow Single-Ended SCSI Bus Length The maximum cable length for an Ultra Narrow Single-Ended SCSI bus is 3 meters. The HP V meters of this maximum cable length. NOTE When calculating the total Ultra Narrow Single-Ended SCSI cable/bus/...
Page 129: Ultra2 Wide Low-Voltage Differential Scsi Bus Length
Length The maximum cable length for an Ultra2 Wide Low-Voltage Differential SCSI bus is 12 meters. The HP V uses 1 meter of this maximum cable length internally. This means that up to 11 meters of cable can be used for connecting external Ultra2 Wide Low-Voltage Differential SCSI devices to this workstation.
Page 130: Assigning Scsi Device Ids
SCSI Connections Assigning SCSI Device IDs Assigning SCSI Device IDs Before assigning a SCSI device ID to a new SCSI device, you need to determine which SCSI device IDs are available. To view the SCSI IDs already in use, type the following command at the prompt and press Enter: /usr/sbin/ioscan -f After a few moments, the ioscan utility lists all of the I/O devices it could...
Page 131: Assigning Ultra Narrow Single-Ended Scsi Device Ids
10/2/3/0.7.0 10/4 10/6 graphics 10/6/7/0 processor processor memory Assigning Ultra Narrow Single-Ended SCSI Device You can determine which Ultra Narrow Single-Ended SCSI (NSE SCSI) devices are currently in use by reviewing the output from the ioscan command discussed above and looking under the “H/W Path” heading. The entry 10/0/15/0 is the built-in Ultra Narrow Single-Ended SCSI bus.
Page 132: Assigning Ultra2 Wide Low-Voltage Differential Scsi Device Ids
SCSI Connections Assigning SCSI Device IDs Assigning Ultra2 Wide Low-Voltage Differential SCSI Device IDs You can determine which Ultra2 Wide Low-Voltage Differential SCSI (LVD SCSI) devices are currently in use by reviewing the output from the ioscan command discussed above and looking under the “H/W Path” heading.
Page 133: Connecting To The Scsi Ports
Connecting to the SCSI Ports This section describes how to connect to the system SCSI ports (Ultra Narrow Single-Ended and Ultra2 Wide Low-Voltage Differential). System SCSI Port Connection The system contains two SCSI connectors: • Ultra Narrow Single-Ended SCSI (NSE SCSI) connector •...
Page 134 SCSI Connections Connecting to the SCSI Ports Chapter 7...
Page 135: The Boot Console Interface
The Boot Console Interface This chapter describes the different features of the boot console interface and how to use them.
Page 136: Boot Console Interface Features
The Boot Console Interface Boot Console Interface Features Boot Console Interface Features There are times when you want to interact directly with the hardware of your computer before it boots the operating system. Your computer provides a menu-driven boot console interface that allows you to perform special tasks, display information, and set certain system parameters, even if the operating system is unavailable.
Page 137 Here are the menus: ------- Main Menu ------------------------------------------------------------- Command ------- BOot [PRI|ALT|<path>] PAth [PRI|ALT|CON|KEY] [<path>] Display or modify a path SEArch [DIsplay|IPL] [<path>] COnfiguration [<command>] INformation [<command>] SERvice [<command>] DIsplay HElp [<menu>|<command>] RESET ------- ------- Configuration Menu ---------------------------------------------------- Command ------- AUto [BOot|SEArch|STart] [ON|OFF] Display or set specified flag BootID [<proc>] [<boot ID>] BootINfo...
Page 138 The Boot Console Interface Boot Console Interface Features ------- Information Menu ------------------------------------------------------ Command ------- BootINfo CAche ChipRevisions CoProcessor FwrVersion LanAddress MEmory PRocessor WArnings BOot [PRI|ALT|<path>] DIsplay HElp [<menu>|<command>] RESET MAin ------- ------- Service Menu ---------------------------------------------------------- Command ------- ChassisCodes [<proc>|ON|OFF] CLEARPIM EepromRead [<addr>] [<len>] MemRead <addr>...
Page 139: Accessing The Boot Console Interface
2. Press the power switch on the front panel of the computer. NOTE There is no need to manually shut down the HP-UX operating system on your computer before powering it off. When you turn off the power switch, your computer automatically shuts down the operating system cleanly before terminating the power.
Page 140: Booting Your Computer
Boot terminated The Main Menu of the boot console appears. Booting your Computer You usually start your computer by turning it on and waiting for HP-UX to boot automatically. However, you may not always want the usual sequence to occur.
Page 141 ISL is the program that actually controls the loading of the operating system. By interacting with ISL, you can choose to load an alternate version of the HP-UX operating system. To interact with the ISL, you must enter no (N).
Page 142 The Boot Console Interface Booting your Computer computer from the backup kernel (/stand/vmunix.prev), type the following at the ISL> prompt and press ISL> hpux /stand/vmunix.prev • If you do not know which media in you ﬁle systems have bootable operating systems, you can ﬁnd them with the search ipl command. See the subsequent section “Searching for Bootable Media.”...
Page 143: Searching For Bootable Media
Searching for Bootable Media To list devices that contain bootable media, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter, and then type the following at the prompt and press Main Menu: Enter command> search ipl The search command searches all buses.
Page 144: Resetting Your Computer
The Boot Console Interface Resetting Your Computer Resetting Your Computer To reset your computer to its predeﬁned values, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter, and then type the following at the prompt and press Enter Main Menu: Enter command>...
Page 145: Displaying And Setting Paths
Displaying and Setting Paths A path is the hardware address of a device that is attached to the I/O system of your computer. The path command sets the system paths shown in the table below. The path command sets and displays the hardware address of a speciﬁed device attached to the I/O bus of your computer.
Page 146 The Boot Console Interface Displaying and Setting Paths To display the current setting for a particular system path, follow the directions in “Accessing the Boot Console Interface” on page 139, and then type the following at the prompt and press Main Menu: Enter command>...
Page 147: Displaying And Setting The Monitor Type
Displaying and Setting the Monitor Type Your system ships from the factory preset to use a monitor with a speciﬁc resolution and frequency. If you replace your computer’s monitor with a different type of monitor, you may have to reconﬁgure your computer to support the new monitor.
Page 148: Displaying The Current Monitor Conﬁguration
The Boot Console Interface Displaying the Current Monitor Conﬁguration Displaying the Current Monitor Conﬁguration To display the current monitor conﬁguration for your system from the Conﬁguration Menu of the boot console interface, follow the directions in “Accessing the Boot Console Interface” earlier in this chapter. Once you are in the Boot Console Interface Main Menu, type the following command and press Main Menu: Enter command>...
Page 149: Setting The Monitor Type
Setting the Monitor Type You can set the monitor type for a graphics adapter by typing the following at the prompt and pressing Configuration Menu: Enter command> monitor graphics(n)tt where n is the number of the graphics adapter and tt is the monitor type. To display a list of supported monitors that are used by your graphics card, type the following command at the prompt and press Configuration Menu: Enter command>...
Page 150 The Boot Console Interface Displaying the Current Monitor Conﬁguration The boot console displays a message that tells you that your new monitor selection will take effect the next time you reboot your system. The boot console also displays the new monitor information. NOTE You must set the console path to get console messages on the monitor: path con graphics(4)
Page 151: Setting The Monitor Type At Power On
Setting the Monitor Type at Power On If you replace you computer’s monitor with a different monitor type, and you do not set the computer’s graphics parameters by using the monitor command before doing so, you may need to perform the following if your screen is blank: Wait two seconds after the boot sequence, then press...
Page 152 The Boot Console Interface Setting the Monitor Type at Power On Next, the following message is displayed: To select a new Graphics Monitor Type press the <TAB> key now, otherwise EXIT by entering any other key (or will time out in 15 seconds)... To restart the monitor selection process, press TAB.
Page 153: Changing The Console To External Terminal
The Boot Console Interface Changing the Console to External Terminal Changing the Console to External Terminal In the event that your console stops displaying to your graphics device, use the following procedure to display the console to an external serial terminal so that you can conﬁgure the graphics console: 1.
Page 154: Displaying The Memory Conﬁguration
The Boot Console Interface Displaying the Memory Conﬁguration Displaying the Memory Conﬁguration The following sample screen output uses the memory command to show memory conﬁgurations both with and without errors. To display the current memory conﬁguration for you system, from the Information Menu of the boot console interface, follow the directions in “Accessing the Boot Console Interface”...
Page 155: Memory Information Examples: 8-Slot J5Xxx
Memory Information Examples: 8-Slot J5xxx The following example, from a J5xxx, shows the Memory Information display when memory modules are improperly installed and conﬁgured: MEMORY INFORMATION MEMORY STATUS TABLE Slot Size Status ---- ------ ------------- 512MB Active 256MB Active-MBE 256MB Active TOTAL MEMORY = 1024MB MEMORY FAULT TABLE...
Page 156 The Boot Console Interface Displaying the Memory Conﬁguration Below is a sample from a J5xxx in which the memory checks out ﬁne; note the lack of entries in the Memory Fault Table: MEMORY INFORMATION MEMORY STATUS TABLE Slot Size Status ---- ------ -------------...
Page 157: Memory Information Examples: 16-Slot J7Xxx
Memory Information Examples: 16-Slot J7xxx The following sample shows the memory-analysis display when memory modules are not properly installed and conﬁgured. In this sample, the DIMM in Slot 4A is of a different size than the DIMM in Slot 4B (they must be equal in size).
Page 158 The Boot Console Interface Displaying the Memory Conﬁguration And here is a good memory display; the lack of entries in the Memory Fault Table indicates that the conﬁguration is correct: MEMORY INFORMATION MEMORY STATUS TABLE Slots Size(A) Status(A) ----- ------- ------------- 0a/0b 512MB...
Page 159: Displaying The Status Of The System I/O
Displaying the Status of the System I/O The I/O command lets you identify all built-in I/O devices and optional I/O devices installed in the option slots. It is available in the Information Menu. To use the IO command from the Information Menu of the boot console, type the following command at the prompt and press Information Menu: Enter command>...
Page 160: Setting The Auto Boot And Auto Search Flags
The Boot Console Interface Setting the Auto Boot and Auto Search Flags Setting the Auto Boot and Auto Search Flags The auto boot and auto search ﬂags are variables stored in your computer’s nonvolatile memory. (Nonvolatile memory retains its contents even after power is turned off.) If you reset these ﬂags to new values, the change takes effect the next time you reboot the computer.
Page 161: Displaying And Setting The Security Mode
Displaying and Setting the Security Mode The SECure ﬂag is a variable stored in non-volatile memory. (Non-volatile memory retains its contents even after power is turned off.) If you reset this ﬂag to a new value, the change takes effect the next time you reboot the computer.
Page 162: Displaying And Setting The Fastboot Mode
The Boot Console Interface Displaying and Setting the Fastboot Mode Displaying and Setting the Fastboot Mode When fastboot is enabled (set to on), your computer does a quick check of the memory and skips I/O interface testing during its power-on self tests.
Page 163: Displaying The Lan Station Address
Displaying the LAN Station Address It is sometimes necessary to supply a LAN station address of your computer to other users. For example, if your computer is to become a member of a cluster, the cluster administrator needs to know your LAN station address in order to add your computer to the cluster.
Page 164 The Boot Console Interface Displaying System Information Chapter 8...
Page 165: Troubleshooting
Troubleshooting This chapter contains information to help you determine what is wrong with your system when you have problems. If you have a problem that is not listed in this chapter, or if your problem persists, contact your designated service representative.
Page 166 The instructions in this chapter assume you are using the HP-UX version 10.20 or later operating system with the HP CDE graphical interface. When using HP CDE, you will have to use command line options in a terminal window to perform tests.
Page 167: Common Problems And Solutions
Common Problems and Solutions The tables in this section list common problems you may encounter with your computer. The tables also tell you what to do to help solve the problems. Table 9-1 Problems Powering Up the System Problem The power LED does not light.
Page 168 Troubleshooting Common Problems and Solutions Table 9-2 Problems Loading and Booting the Operating System Problem The power LED is lit, and text appears on the screen, but more than two minutes have passed with no sign of system activity. The system stops or hangs while booting.
Page 169 Table 9-4 Problems Using a Hard Disk Drive Problem The disk drive is not accessible or does not respond. If problems persist, contact your system administrator or call your designated service representative. Table 9-5 Problems Using the CD-ROM Drive Problem The CD-ROM drive does not respond to commands.
Page 170 Troubleshooting Common Problems and Solutions Table 9-6 Problems Using the DDS Tape Drive Problem The DDS drive does not respond to commands. If problems persist, contact your system administrator or call your designated service representative. Table 9-7 Problems Using the Floppy Disk Drive Problem The ﬂoppy drive does not respond to commands.
Page 171 Table 9-7 Problems Using the Floppy Disk Drive Problem If problems persist, contact your system administrator or call your designated service representative. Chapter 9 Common Problems and Solutions Solution Troubleshooting...
Page 172: Dealing With A Boot Failure
4. If your computer still fails to boot, there is either something wrong with the ﬁle system or with the hardware. If you suspect a ﬁle system failure, see the manual Using HP-UX for help on dealing with ﬁle system failures (And make sure the SCSI terminators are in place!) If you think that something is wrong with the hardware, continue reading this chapter for more troubleshooting information.
Page 173: Memory Failures
Note that you must be superuser (root) to use the commands in this section. HP-UX 10.20 uses Memory Page Deallocation information to map out the failing memory areas, and continue normal operation. You can use the...
Page 174: Lcd-Indicated Problems
Troubleshooting LCD-Indicated Problems LCD-Indicated Problems Your computer uses an LCD panel to display ﬁrmware/OS progress codes. The codes, referred to as chassis codes, consist of one of the mnemonics listed below, followed by a 4-digit hexadecimal number identifying the code module being executed. The mnemonics and the meaning are: Fault: A hardware error has been detected Test: Hardware being tested...
Page 175: Running System Veriﬁcation Tests
HP-UX 10.20 media kit). If the Support Tools Manager is installed, you can access it in a terminal window. If you are using HP CDE as your interface, you can also access the Support Tools Manager through the sys_admin directory.
Page 176 Troubleshooting Running System Veriﬁcation Tests A terminal window opens. 2. Move the mouse cursor into the terminal window and click the left mouse button. 3. Type the following at the shell prompt and press cstm The following is displayed on the screen: Support Tool Manager Type ‘help’...
Page 177: Safety And Regulatory Statements
Safety and Regulatory Statements...
Page 178: Declaration Of Conformity
Safety and Regulatory Statements Declaration of Conformity Declaration of Conformity Appendix A...
Page 179: Emissions Regulations
• Ask the dealer or an experienced radio/television technician for help. Hewlett-Packard's system certiﬁcation tests were conducted with HP- supported peripheral devices and HP-shielded cables, such as those you receive with your computer. Changes or modiﬁcations not expressly approved by Hewlett-Packard could void the user's authority to operate the equipment.
Page 180: Special Video Conﬁguration Statements
Safety and Regulatory Statements Declaration of Conformity Special Video Conﬁguration Statements The following statements apply only to those applications which include a cable connected to the S-Video connector on the A4248A card. No modiﬁcation to the regulatory statements is necessary for applications which include cables connected to other connectors on the card but not to the S-Video connector.
Page 181: Vcci Class 2 Ite
VCCI Class 2 ITE Figure A-1 EMI Class A RRL (Korea) Figure A-2 VCCI Class B ITE (Japan) Figure A-3 EMI Class A (Taiwan) Appendix A Safety and Regulatory Statements Declaration of Conformity...
Page 182: Laser Safety Statement (U.s.a. Only)
Safety and Regulatory Statements Declaration of Conformity Emissions Regulations Compliance Any third-party I/O device installed in HP system(s) must be in accordance with the requirements set forth in the preceding Emissions Regulations statements. In the event that a third-party noncompliant I/O device is installed, the customer assumes all responsibility and liability arising therefrom.
Page 183: Warnings And Cautions
Safety and Regulatory Statements Declaration of Conformity Warnings and Cautions Appendix A...
Page 184 Safety and Regulatory Statements Declaration of Conformity Appendix A...
Page 185: Environmental And Electrical Speciﬁcations
Environmental and Electrical Speciﬁcations...
Page 186: Environmental Speciﬁcations
Environmental and Electrical Speciﬁcations Environmental Speciﬁcations Environmental Speciﬁcations Altitude Operating: 0-10,000 ft. (0-3000m) Non-operating (storage or shipping): 0-15,000 ft. (0-4500m) DC Magnetic Field Interference Operating: <1 Gauss at surface of product Non-operating: <2 mGauss @ 7 feet Temperature Operating: 5 to +40˚ C Non-operating (shipping or storage): -40 to +70˚...
Page 187: Electrical Speciﬁcations
Electrical Speciﬁcations Power Requirements Table B-1 Input Power (Maximum Current RMS) Voltage 100V 120V 200V 230V Appendix B Environmental and Electrical Speciﬁcations Electrical Speciﬁcations J5xxx J7xxx 12.2A 19.3A 10.2A 16.0A 6.1A 9.7A 5.4A 8.4A...
Page 188 Environmental and Electrical Speciﬁcations Electrical Speciﬁcations Appendix B...
Page 189: Glossary
Glossary Absolute pathname The full pathname of a ﬁle, including all the directories leading to it, starting with the root directory (“/”) and ending with the ﬁlename itself. See also File, Filename, Pathname. Access permissions Settings that allow (or prevent) a user or group of users to read, write, or execute ﬁles See also File Access Permissions.
Page 190 Glossary diskless workstations. See also boot ROM. Boot Console Interface The interactive ﬁrmware that enables you to interact with the hardware of your workstation before the workstation boots the operating system. The boot console interface allows you to perform special tasks, display information, and set certain system parameters.
Page 191 ﬁle-system server for the cluster clients. See also Cluster client, Cluster node, Cluster server. Cluster client. A cluster node that does not have a local HP-UX ﬁle system. Its ﬁle system resides on the cluster server. See also Cluster, Cluster node, Cluster server.
Page 192 This automatic option is called the “default” See also Command option. Dialog box A special type of HP CDE screen that contains controls and settings, and with which the user can carry on an interactive “dialog” in the process of setting...
Page 193 Single Inline Memory Module Directory A special type of “container” object that contains information about the objects beneath it in the HP-UX organizational structure. Basically, it is a ﬁle that stores names and links to ﬁles and other directories See also File.
Page 194 ﬁle (such as opening the ﬁle or writing to it) See also Access permissions. File Manager The HP CDE application that allows you to...
Page 195 If it is removable, it is contained in a protective cover that is opened by the drive when access is needed. Help Manager The HP CDE application that provides online help. $HOME The environment variable that contains the name of a user’s home directory.
Page 196 X Window system), enabling you to control your workstation by directly manipulating graphical objects instead of by typing commands at a command-line prompt. HP-UX. This is Hewlett-Packard Company’s version of the UNIX® operating system. HP-UX cluster See Cluster node, Cluster server.
Page 197 Glossary ready for use. Instant ignition is the result of the computer’s operating system being preloaded at the factory. Install server. This is a networked computer from which ﬁle sets and operating systems can be installed. Internet Protocol address (IP address) A string of characters, in the format nnn.nnn.nnn.nnn, that uniquely identiﬁes a...
Page 198 (LAN) connection for your workstation at the hardware level. This 48-bit number is preassigned by HP on their computers and it must never be changed. Log in v. To initially sign on to the system so that you may begin to use it.
Page 199 Operating system The program that supervises the execution of other programs on your workstation. For example, the entire HP-UX system, including the kernel and all HP-UX commands See also kernel. Option See Command option. Output device Any of several pieces of hardware used for...
Page 200 (this is used as a visual feedback mechanism from a program to the user). In the HP CDE Workspace, the default pointer is an X; on a window frame, it is either a simple arrow, or an arrow with one or...
Page 201 Also called a “work session” or a “login session.” See also Current Session. Shell A command-line interpreter program used to invoke programs. Some examples of HP-UX shells are the Bourne, Korn, Key, and C shells. Sometimes referred to as a “command interpreter.” See also Command interpreter.
Page 202 DIMM cards. Standalone A workstation that is not part of a cluster See also Cluster. Style Manager The HP CDE application that provides the ability to customize various user-interface aspects of your system, including colors, fonts,...
Page 203 System name Same as Hostname or Nodename See also Internet Protocol Address. Terminal window A terminal window is a type of HP CDE window that emulates a complete display terminal. Terminal windows are typically used to fool window-dumb programs into believing they are running in their favorite terminal.
Page 204 Working directory Current Working Directory. Workspace What the screen becomes when you start HP CDE. Although you can hide the workspace under terminal windows or other graphic objects, you can never position anything behind the workspace. All windows and graphic objects appear stacked “on top of”...
Page 205 Index Symbols $HOME, Numerics 802.3 Network Connectors absolute pathname, ACE (Additional Core Enhancements) active window, Additional Core Enhancements (ACE) ANSI, archiving data listing ﬁles, restoring ﬁles, saving to a cassette, archiving data, argument, attachment unit interface (AUI), Audio Connectors back up, Accessing Menus Conﬁguration...
Page 206 Headphone jack home directory, Host name host name, host, Hot-Plug Disk Drives Example Procedure Hot-Pluggable Disk Drives vs. Hot-Swappable HP Visual User Environment, HP VUE, HP-UX 10.20 HP-UX cluster, I/O Board Installing I/O Slot Speed icon, iconify, iconize, Initial System Loader,...
Page 207 Index Installation CD Drive DDS Drive Disk Drive Floppy Drive Installing I/O Card Memory PCI Card Instant Information Interlock Power Supply Internet protocol address internet protocol address, invisible ﬁlename, ioscan ioscan command IP address, ISL, kernel, Keyboard Connectors LAN station address, LAN, Left Side Panel Lifting Ledge...
Page 208 Index Installing RAM (Random-Access Memory) RAM, Related Manuals Removeable-media Devices Removing Disk Drive Resetting the Computer Revision History Right Side Panel RJ45 Connector ROM, root, RS-232C Connectors SAM (System Administration Manager) scroll bar, SCSI Narrow Single-Ended Wide Low-Voltage Differential SCSI bus Conﬁguration constraints Device IDs Differences...

This manual is also suitable for:

Visualize j7000

HP Visualize J5000 Owner's Manual

1 System Overview

2 Changing Your Computer's Hardware Conﬁguration

3 Hot-Pluggable Hard Disk Drives

4 Using Your CD Drive

5 Using Your Digital Data Storage (DDS) Tape Drive

6 Using Your 3.5-Inch Floppy Disk Drive

7 SCSI Connections

8 The Boot Console Interface

9 Troubleshooting

Safety and Regulatory Statements

Environmental and Electrical Speciﬁcations

Glossary

Quick Links

Related Manuals for HP Visualize J5000

Summary of Contents for HP Visualize J5000

This manual is also suitable for:

Table of Contents
