Hot-Pluggable Hard Disk Drives

The Disk Drives

The Disk Drives
When reconfiguring your computer's internal hardware, always wear a
properly grounded wrist strap to avoid damaging components.
Figure 3-1 System Unit with Front-Panel Door Open
The above illustration shows that the four hard disk drives are accessible
simply by opening the door on the front panel (also known as the "bezel,"
pronounced "bezz-ull"); it is unnecessary to remove the entire panel.
From a hardware point of view, these four disk drives are
interchangeable: one drive will work as well as any other in any given
slot. And, you need not set the SCSI bus addresses for these drives: their
74
Floppy Drive or
DDS Drive Bay
Power switch
System LCD
Interchangeable
hard disk drives
CD Drive
Chapter 3
