The illustration below shows the physical layout of the PCI slots:
Figure 2-13 PCI Slots in a J5000/J7000
Power Supply
PCI Card
Retaining Clip
PCI Card Slots
(Slot 7 is the
primary graphics
slot; Slot 4 is the
secondary)
PCI Card
Cooling Fan
Follow these steps to install a PCI board into your computer:
1. Remove the top and right-side panels from your computer, as
2. Remove the PCI card retaining clip—the instructions for doing so are
3. Determine the appropriate slot(s) for the card you are inserting.
Chapter 2
Changing Your Computer's Hardware Configuration
described in the section "Opening the System Unit," earlier in this
chapter.
on the label on the side of the power supply, right above the PCI slots.
This is a simple snap-on clip; no tools are required to remove it or
install it again. (Note: during re-installation of the retaining clip,
make sure the hook on the bottom of the clip fits into the hole on the
floor of the chassis.)
Relevant information includes the voltage (3.3 or 5 volts) and the
speed (33 or 66 MHz). Again, when multi-card sets are inserted, it's
the bottom card that goes into the indicated slot. Thus, to insert a
6
V card (a two-card sandwich) "into" Slot 7, you'd put the
ISUALIZE FX
bottom card into Slot 7, and the top card into Slot 6.
Installing a PCI-Type I/O Board
Slot:
1
2
3
4
5
6
7
8
