USB Printer Information
This section applies to HP Jetdirect external print servers with USB printer connections only. USB
information on the HP Jetdirect configuration page is described below. For non-HP devices, some
information may not be available.
Table 8-3 USB Printer Information
Message
Device Name
Manufacturer
Serial Number
Communication Mode
USB SPEED

Security Settings

Information in this section of the Jetdirect configuration page is described below.
Table 8-4 Security Settings
Message
802.1X
ENWW
Description
Name of the attached USB printing device, supplied by the manufacturer.
Manufacturer of the attached printing device.
The Manufacturer's serial number for the attached printing device.
Current USB communication mode:
● Composite USB: For multiple interface (Composite USB) devices that allows
simultaneous print, scan and status communications.
●
IEEE 1284.4: IEEE standard protocol, a mode for printers and multi-function (All-
in-One) devices that allows multiple channels of simultaneous print, scan, and
status communication.
● MLC: HP-proprietary protocol for Multiple Logical Channels, a mode for printers
and multi-function (All-in-One) devices that allows multiple channels of
simultaneous print, scan, and status communication.
● Bidirectional: Two-way printer communication, sending print data to the printing
device and returning status information from the printing device.
●
Unidirectional: One-way communication to the printing device.
● Device not found: The connection of a printing device has not been detected.
Check device and cable.
●
Device not supported: The device connected is not a printer (for example, a
camera).
(USB 2.0 print servers only) Specifies the autonegotiated communication speed over
the USB connection between the print server and the device.
Full Speed: 12 Mbits/sec as specified in the USB v2.0 specifications, compatible with
USB v1.1 specifications.
Hi-Speed: 480 Mbits/sec for USB v2.0 devices only.
Disconnected: The USB port is not connected.
Description
Identifies whether the print server has been configured with EAP/802.1X client
authentication settings.
EAP-TLS: 802.1X EAP-TLS has been configured.
EAP-PEAP: 802.1X EAP-PEAP has been configured.
HP Jetdirect Configuration Page 131
