Dlc/Llc Protocol Information; Error Messages - HP 635n - JetDirect IPv6/IPsec Print Server Administrator's Manual

Table 8-11 AppleTalk
Message
STATUS
NAME
ZONE
TYPE
NETWORK NUMBER
NODE NUMBER

DLC/LLC Protocol Information

Information in this section of the Jetdirect configuration page is described in
Configuration Information on page
Table 8-12 DLC/LLC
Message
STATUS:

Error Messages

Error codes and messages that may appear in the Status sections of the Jetdirect configuration page
are described in
ENWW
Configuration Information
Description
Indicates the current AppleTalk configuration status.
READY: Indicates the HP Jetdirect print server is awaiting data.
DISABLED: Indicates that AppleTalk was manually disabled.
INITIALIZING: Indicates that the print server is registering the node address or name.
An additional status message may also be displayed.
An error code and message is displayed if the print server is not ready. For more
information, see
The name of the printer on the AppleTalk network. A number after the name indicates
that there are multiple devices with this name, and this is the Nth instance of the name.
The name of the AppleTalk network zone on which the printer is located.
The type of the printer being advertised on the network. Two types can be displayed.
NETWORK
Jetdirect print server is currently operating.
NODE NUMBER: Identifies the AppleTalk Node Number that the print server chose for
itself as part of its initialization sequence.
NOTE:
Jetdirect print server.
139.
Configuration Information
Description
Indicates the current DLC/LLC protocol status.
READY: Indicates the HP Jetdirect print server is awaiting data.
DISABLED: Indicates that DLC/LLC was manually disabled.
INITIALIZING: Indicates that the print server is registering the node address or name.
An additional status message may also be displayed.
An error code and message is displayed if the print server is not ready. For more
information, see
Table 8-13 Error Messages on page
Table 8-13 Error Messages on page
NUMBER: Identifies the AppleTalk Network Number on which the HP
The AppleTalk phase 2 (P2) parameter is pre-configured on the HP
Table 8-13 Error Messages on page
140.
HP Jetdirect Configuration Page 139
140.
Table 8-12 DLC/LLC
140.
